Altronix eFlow104N Series Installation Manual page 6

Fig. 2 - Battery trouble indication
For Canadian use, a red indicating lamp must be visible from the exterior of this enclosure.
Wire one leg of a UL Listed, power-limited power source to the indicating lamp.
Wire the second leg of the power source to the indicating lamp in series with the battery fail relay contact termi-
nals marked [BAT FAIL - C, NO] (Fig. 2, pg. 6).
AC FAIL
POWER
NC C NO
SOURCE
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Fig. 3a - PD8UL Power Distribution Board
Non Power-Limited Outputs
Replace fuses with the same type and rating 3.5A/250V
1 2 3 4
P
FUSED POWER OUTPUTS
N
COMMON POWER OUTPUTS
DC Output to devices
1P-8P Power Outputs,
1N-8N Common Outputs
Fig. 4a - PD16W Power Distribution Board
Non Power-Limited Outputs
DC Output to devices
1P-16P Power Outputs, 1N-16N Common Outputs
common
1 2 3 4 5 6 7 8
outputs
protected
outputs
For continuous protection against risk of fire
replace fuses with same type and rating
3.5A 250V
- 6 -
BAT FAIL
NC C NO
Power Distribution Module(s):
5 6 7 8
D1
R1
INPUT
From Power Supply
Board
(Factory Installed)
9 10 11 12 13 14 15 16
N
P
RED INDICATING
LAMP
Fig. 3b - PD8ULCB - Power Distribution Board
1
P
FUSED
LED
N
COMMON POWER OUTPUTS
Fig. 4b - PD16WCB - Power Distribution Board
1P-16P Power Outputs, 1N-16N Common Outputs
1 2 3 4 5 6 7 8
From
Power
Supply
Board
(Factory
Installed)
Class 2 Power-Limited Outputs
2 3 4 5 6 7
POWER OUTPUTS
DC Output to devices
1P-8P Power Outputs,
1N-8N Common Outputs
Class 2 Power-Limited Outputs
DC Output to devices
common
9 10 11 12 13 14 15 16
outputs
protected
outputs
eFlow104N Series Installation Guide
8
D1
LED
R1
INPUT
From Power Supply
Board
(Factory Installed)
N
P
From
Power
Supply
Board
(Factory
Installed)
