Depth Camera
Interface
Docking Camera
12V -DISP
USB-Type-C
Design drawing of 12V -DISP terminal
USB3.0 Connected to the RK3399
development via USB3.0 to
obtain information.
USB2.0 Connected to the RK3399
development via USB3.0 to
obtain information of code
scanning camera.
Rated 12V working power of
Voltage Cube2 to provide the
12V external display screen of
human-computer
(See the
interaction.
figure
below for
the design
drawings)
USB3.0 Used for communication
between 3399 and Cube2.
11 / 56
Need to pay
attention to the
left and right
sequence.
Assist precise
docking.
Maximum current
2A
Connect to
Hub3.0
