Power connector
Main board
specifications
Operating system
Working environment
Remark：
①RK3399 is dual-core Cortex-A72 (the highest frequency is 1.8GHz) + 4-core Cortex-A53 (the highest
frequency is 1.4GHz);
②The eDP interface and the LVDS interface share the backlight and control signals, and cannot be
connected to the screen at the same time, only one of the two can be selected;
③WIFI specifications：802.1b/n/g @ 2.4GHz; Bluetooth specifications：Bluetooth 4.0；
④COM1 is the Debug interface and supports TTL/RS232, COM2 can communicate with the onboard
MCU, and can also be used as an external RS232/RS485 interface;
⑤TF card supports maximum expansion to 128GB.
（2）Size of main board
2 A/D conversion pin
2*MIPI-CSI2 camera expansion port
1*G-Sensor gravity sensor
DC2.5*5.5 socket/PH2.0-4pin，12V DC input
146*102*22mm， green
Android 7.1
Temperature：0~+40℃
Humidity： 30~70%RH
16 / 56
Unit: mm
