Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
Important!
TL11 requires either CAN or IMMO connections. An Analog Firmware is recommended if CAN connections are
NOT used and the vehicle does NOT have a transponder. The TL11 installation guides can be used for wire and connection
details.
Important:
For Toyota Solaras with a V6 engine, the TACH wire can be found at the ECM behind glove box, top white
connector.
Some Toyota 2010+ models have different encryption types. Please look at your key blade and identify the markings. A dot
"." means the vehicle is compatible with TL11 firmware. "G" or "H" indicates the vehicle is not compatible with this firmware.
Refer to "Key Types" for more information. Note: some replacement keys may not have any markings on the key.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
Refer to the "Vehicle connections" following the installation diagram.
General notes: This section highlights important information for this specific firmware.
Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.
[1]
The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin or
[2]
NOT supported in data.
Second starter connection may be required in some vehicles.
[3]
Keysense connection may be required in some vehicles to disarm factory alarm.
[4]
Trunk release connection may be required in some vehicles
[5]
5
403.TL11 1.15 2004 Toyota Camry
©2022 VOXX•DEI LLC. All rights reserved.
Keys required for
Keys required for
1
programming
operation
0
