gle between calibration for foot pedal 1 and foot pedal 2. The horizontal
bar graph at the top of the menu page represents the current foot pedal
position relative to the calibration.
To calibrate your pedal, first select
Press .
<CAL>
Then select and rock it all the way forward. Press
(TOE)
You're done. Now when you use that foot pedal to modulate parameters, the minimum foot pedal position
will correspond to no modulation and the maximum foot pedal position will correspond to maximum
modulation. If you want the opposite to occur (maximum foot pedal position corresponding with no modu-
lation and minimum foot pedal position corresponding with maximum modulation), simply calibrate the
pedal as discussed above and then swap the heel and toe values by entering them with the keypad.
Eclipse User Manual
Eclipse User Manual
and rock it all the way back.
(HEEL)
<CAL>
