Scaling Modules And Selecting Modulation Type - Eventide Eclipse User Manual

One of four "generic" parameters modules located at
page 2
gram parameters to one of the generic parameters, you can alter all of the patched parame-
ters in concert simply by adjusting the generic parameter. Pretty handy.
Use to view the current value of the module selected under
(MONITOR)
. To the right, we see a value of about
(SOURCE)
something very dynamic like
jump around quite a bit.
Parameters with active modulations applied will have their names under-
lined on the softkey labels.

Scaling Modules and Selecting Modulation TYPE

Here's the situation: let's say you've selected
filter cutoff frequency
will the filter be at 0Hz? You wouldn't hear anything. When the LFO is at
the top of its cycle, will the filter be at 20,000Hz? This might be what you
want, but maybe you only want the filter to cycle between 2000Hz and
3000Hz. How can we make that happen?
Here's the solution: Scaling. Before holding down the
enter a value of 2000Hz. We'll call this value the "base" value below.
Now, hold down the soft key and press
and press HOTKEY to nagivate to page two where the Scale parameter is
located. The total range of possible modulation (
frequency parameter is 0 ~ 20,000, but we only want a modulation of 3,000
– 2,000 = 1,000. To scale, enter the value of 1000 in the
Great! Now we need to select the
choices:
unipolar unipolar
point and adds the modulation value to it.
In the example above, the parameter value will vary between 2,000 and 3,000 (it starts at the
base value and modulates up).
bipolar bipolar
In the example above, the parameter value will vary between 1,500 and 2,500 (centering on
the base value). Note that for bipolar, the scale setting reflects the amount the parameter
will vary above and below the base value.
absolute absolute
mum to maximum parameter for the swing of the modulation.
In the example above, the parameter value will vary between 20 and 2,000.
So, continuing our example, we would select
get modulation between 2,000 and 4,000Hz.
Finally, select under
lfo#1
For a good time (or to troubleshoot), watch your parameter vary (
in this case). Neat!
