(PGM -) Allows you to select a foot pedal or a MIDI source to load the next lowest program. Of
course, this can be set to

Setting the Trigger Switch Mode

The dedicated external controllers are trigger type controls – that is, they do
not have a value themselves, but instead cause an event to occur when the
appropriate criteria is satisfied by the modulation source's value.
Normally, trigger events occur when the modulation source transitions
from a value less than 50% to a value more than 50%. This works very well
for remote controllers with momentary type switches. However, for a remote
controller with a latching (on/off) switch, it is desireable for a trigger event
to occur when the modulation source transitions 50% in either direction.
The (TRIGMODE) parameter accommodates both of these switch types using
one of two settings:
Causes the trigger event (i.e. Bypass, PGM+, or PGM-) to occur each time the modulation
Momentary
sources transitions from a value below 50% to a value at or above 50%. Useful for remote
sources that use momentary switches.
On/Off Causes the trigger event to occur each time the modulation source transitions through 50%
from either direction. Recommended for modulation sources that use latching (on/off) type
switches.
In the Eclipse, MIDI can be used:
• with programs that explicitly call for some sort of "external" controller. For example, a program called
" " might call for MIDI notes to adjust the amount of pitch shifting that is applied to an
MidiHarmony
audio signal.
• to remote control almost any parameter in the Eclipse (including input and output levels) via external
controllers.
see page 40
• to change programs via MIDI program change messages.
• to "dump" information from one Eclipse to another or to an external storage device.
Several MIDI global parameters bear on all of the above uses of MIDI func-
tion. These parameters are found under
each parameter in turn, shall we?
If page 2 MIDI CHANNEL
SETUP
mands are ignored. Settings of
be the base channel from which MIDI channel numbers will be calculated
elsewhere in the Eclipse. Finally, if set to
channel is accepted and dutifully obeyed by every MIDI message recipient
in the Eclipse. This keeps things simple for simple setups.
page 2
MIDI MIDIMODE
SETUP
This determines whether the Eclipse will accept and obey
(PGM CHNG)
MIDI program change messages.
Eclipse User Manual
Eclipse User Manual
as well.
Off

MIDI Setup

page 2
SETUP
is set to Off , all received MIDI com-
to select one of 16 MIDI channels to
1 16
Omni , a MIDI message on any
Page 46 of 64
see page 29
. Let's look at
MIDI
see page 50
