Scaling Modules and Selecting Modulation TYPE

Here's the situation: let's say you've selected
filter cutoff frequency
(FREQ)
will the filter be at 0Hz? You wouldn't hear anything. When the LFO is at
the top of its cycle, will the filter be at 20,000Hz? This might be what you
want, but maybe you only want the filter to cycle between 2000Hz and
3000Hz. How can we make that happen?
Here's the solution: Scaling. Before holding down the
enter a value of 2000Hz. We'll call this value the "base" value below.
Now, hold down the soft key and press
and press HOTKEY to nagivate to page two where the Scale parameter is
located. The total range of possible modulation (
frequency parameter is 0 ~ 20,000, but we only want a modulation of 3,000
– 2,000 = 1,000. To scale, enter the value of 1000 in the
Great! Now we need to select the
choices:
unipolar unipolar
point and adds the modulation value to it.
In the example above, the parameter value will vary between 2,000 and 3,000 (it starts at the
base value and modulates up).
bipolar bipolar
In the example above, the parameter value will vary between 1,500 and 2,500 (centering on
the base value). Note that for bipolar, the scale setting reflects the amount the parameter
will vary above and below the base value.
absolute absolute
mum to maximum parameter for the swing of the modulation.
In the example above, the parameter value will vary between 20 and 2,000.
So, continuing our example, we would select
get modulation between 2,000 and 4,000Hz.

Setting Up the Modulation Block

The Modulation Block

Let it be said: The modulation block is totally cool. It's a collection of
modules residing inside the Eclipse waiting to be patched to effects pa-
parameters. The modulation block exists at
.
MOD>
Changes made to the modulation block are normally saved or loaded with
programs. This can be changed by going to
changing (ModBlock)
tion block will not change as programs are loaded.
Eclipse User Manual
Eclipse User Manual
lfo#1
. When the LFO is at the bottom of its cycle,
<MODULATE>
of modulation. We have three
(TYPE)
uses the base value (the value of the parameter before modulation) as a starting
uses the base value as a starting point and modulates above and below it.
ignores the base value and passes the modulation right through, going from mini-
SETUP
from Prog to Global . If set to
Page 42 of 64
to modulate a low pass
soft key,
(FREQ)
as discussed above,
) for a
parameter_range
setting.
(SCALE)
unipolar under (TYPE)
page 2 <EDIT
PARAMETER
page 1 <modes>
Global , the modula-
to
and
