you load! Put another way, the routing between effects blocks that we're discussing here will change from
program to program depending on what you're trying to achieve with the effect. For example, a pitch shifter
into a reverb ( ) sounds different from a pitch shifter and a reverb (
series
input mode will likely depend on your studio or rack setup. For example, if you're using the Eclipse during a
mixdown, you'll probably want to have the input mode set to
you'll probably want it in
You can route signals between the two effects blocks in five different ways. Press
to choose between them.
(ROUTING)
series The effects of block A are effected by block B. Effecting an
effect, if you will. If you wanted a filtered delay, you'd load
a filter into block A, a delay into block B, and then route the
effects blocks in
Each effects block takes a signal from both inputs, and the
parallel
output of each effects block is summed. If you wanted a
phaser and a delay placed on a signal as if they were coming
from two different units (i.e., not a phased delay!), you'd load
a phaser onto one effects block and a delay onto the other,
and then route the effects blocks in
Each effects block takes its signals from a single input, and
dual
the output of each effects block is summed. This is useful if
you want to effect two different signals. Send a vocal in
channel 1 and load
guitar in channel 2 and load
Use
PARAMETER
relative volume between the vocal effect and the guitar ef-
fect.
Each effects block takes its signals from a single input, and
dual mono
each effects block sends its signals to a single output. This
is similar to
of each effects block are not mixed!
xfade Only one effects block runs at a given time. However, by
setting
value, when you load a program, the old program and the
new program will smoothly crossfade. In addition to creat-
ing unique effects in its own right,
smooth onstage transitions. Note that crossfades are not
possible between all programs.
see page 29 to learn how to load programs with crossfades

Wet/Dry Ratio

With the Wet/Dry ratio you can make an effects block pass its input signal
unaltered ( 0% wet ) or have none of the original signal present – all effect
( ). Or you can have half original signal, half effect (
100% wet
And so on. Press
PARAMETER
to alter this parameter.
area that controls how much of the dry input signal will mix with the signal coming out of the DSP chip
Eclipse User Manual
Eclipse User Manual
Mono (see page 21) .
.
series
VOXPROC
OVERPRE
page 2
LEVELS {FX LVL}
dual described above, except that the outputs
SETUP MODES page 2
page 2
LEVELS {FXA MIX}
Be aware that there is also a "global" wet/dry control in the
Page 38 of 64
stereo
.
parallel
onto effects block A. Send a
onto effects block B.
to control the
(XFADE) to some nonzero
xfade is useful for
50% wet
or
{FXB MIX}
). On the other hand, the
parallel
, but if you're using it with a guitar,
PARAMETER
).
LEVELS
