page 3
EXTERNAL
SETUP
You can make up to eight "connections,"
how one of these "connections" is made.
First, press page 3
SETUP
you want to "connect" with
(MONITOR) . Our choices are:
pedal 1, 2 The input from the pedals at the rear panel foot pedal jacks 1 & 2.
tip 1, 2 tip is fully modulated when a switch connected between tip and sleeve of the rear foot
pedal jack is closed.
ring 1, 2 ring
pedal jack is closed.
tip & ring 1, 2 tip & ring
switch connected between them and the sleeve of the rear foot pedal jack is closed.
MIDI control message 1 - typically assigned to the mod wheel on a MIDI keyboard.
mod wheel
MIDI control message 2 - typically assigned to the breath controller on a MIDI keyboard.
breath con
foot con MIDI control message 4 - typically assigned to the foot controller on a MIDI keyboard.
damper Triggers when a damper control message (MIDI control message 64) is received with
damper = 1.
Triggers when a portamento control message (MIDI control message 65) is received with
portamento
portamento = 1.
Triggers when a sostenuto control message (MIDI control message 66) is received with
sostenuto
sostenuto = 1.
Triggers when a soft control message (MIDI control message 67) is received with
soft
soft = 1.
hold 2 Triggers when a "hold 2" control message (MIDI control message 69) is received with
"hold 2" = 1.
volume MIDI control message 7 - typically assigned to volume changes.
balance MIDI control message 8 - typically assigned to balance.
pan MIDI control message 10 - typically assigned to panning.
expression MIDI control message 11 - typically assigned to the expression controller on a MIDI key-
board.
general 1 – 8 MIDI control messages 16 through 23.
MIDI single Allows selection of any MIDI control number with
coarse quantization. Input range is 0 to 127. A third pa-
rameter appears,
number to be used.
MIDI double Allows selection of any MIDI control number with very
fine quantization. Input range is 0 to 16,383. A third pa-
rameter appears,
Eclipse User Manual
Eclipse User Manual

External Controllers

"connects" external controllers to the Eclipse.
EXT#1
EXTERNAL EXT#1 . Select the external controller
(SOURCE)
is fully modulated when a switch connected between ring and sleeve of the rear foot
are fully modulated when the tip and ring are electrically connected and a
, which selects the controller
(CNTRL)
, which selects the controller number to be used. Your choices
(CNTRL)
Page 44 of 64
through EXT#8 . Let's see
. Monitor its value with
to set these up, see page 47
