When it comes to routing signals inside the Eclipse, it's helpful to think of the effects blocks and the routing

between them as existing within the "DSP."

• All of the levels and signal selection outside the DSP are addressed in the

area. Refer to the "Eclipse System Signal Flow" sheet provided in the pocket of this manual to "look" at

the signal flow outside the DSP. You cannot save these settings as parts of programs.

• All of the routing and levels inside the DSP are addressed in the

gram Signal Flow" sheet provided in the pocket of this manual to "look" at the signal flow inside the

DSP. All of these settings are saved as parts of programs.

This is as confusing as it gets, so if you have this straight you're all set.

... certified ergonomically sound after extensive testing on free-range humans.

Toggle this toggle to "1" to turn the Eclipse on. Toggle this toggle to "0" to turn the Eclipse

POWER

off.

Press this key to load and save programs.

PROGRAM

Press this key to access the most important parameters for the current program. Addition-

HOT KEYS

ally, assign any parameter to the

Press this key to alter input and output levels, system wet/dry mix, system routing (not to be

LEVELS

confused with the routing between the two effects blocks that comprise a program), and me-

tering parameters.

Press this key to access system parameters such as display, digital rate and clock source,

SETUP

MIDI configuration, and much more.

6) Display

This is your window on the inner workings of the Eclipse.

7) Soft Keys

Each of the four soft keys corresponds to the bracketed phrase in the display directly above

it. Pressing a soft key allows the parameters associated with that soft key to be altered.

8) Keypad

The keypad is used to enter parameter values. Negative values can be entered by pressing the

key before or after the number. Numbers entered will not "stick" until you press the

+/-
