Chapter 2: Jumpers and Connectors
LVDS Panel Voltage Select
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: LVDS_PWR
1
1
3
3
Pin
Settings
1-2 On
3.3V
2-3 On
5V
1-2 On: default
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
LVDS Enable Select
Connector type: 1x3 3-pin header, 2.0mm pitch
Connector location: LVDS_DIS
1
1
3
3
Pin
Settings
1-2 On
Enable
2-3 On
Disable
1-2 On: default
11
XPPC 16-101 User Manual
