Chapter 2: Jumpers and Connectors

LVDS Panel Voltage Select

Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: LVDS_PWR
1 1 3 3
Pin Settings
1-2 On 3.3V
2-3 On 5V
1-2 On: default
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.

Backlight Control Voltage Select (Dimming)

Connector type: 1x3 3-pin header, 2.0mm pitch
Connector location: BLT_PWM
1 1 3 3
Pin Settings
1-2 On 3.3V
2-3 On 5V
2-3 On: default
