Diagnostics; View Stream Details - IONODES ION-R200 User Manual

13 Diagnostics

13.1 View Stream Details

In order to help diagnose connectivity or performance problems, the ION-R200 can display live details about
the video displayed in each tile. To display the stream details, click on the
The stream details include:
The name of the data source
•
The connection URI
•
The current connection status
•
The video stream encoding and resolution (not the size of the tile the video is playing in)
•
The video stream framerate
•
The video stream bitrate
•
The network packet lost count (displayed only when one or more packets are lost)
•
Stream details can also be activated from the Configuration > Video Outputs section of the web interface, by
ticking the checkbox at the bottom of the page:
support@ionodes.com | www.ionodes.com | 450-696-1060
button at the top of the screen.
73
