9.16 PTZ Control
The ION-R200 allows you to send PTZ and presets commands directly from any video tile window showing
video from a PTZ-enabled data source. You just need to connect any standard keyboard and mouse to your
ION-R200. Once done, you simply need to select the video tile to display the PTZ control.
Note: Your data source must have Enabled PTZ checked. If this setting doesn't appear, it means your data
source does not support PTZ over ONVIF or was configured with PTZ disabled. Only the ONVIF
Continuous Mode is supported.
The following control should be depicted within your video tile:
1: Pin Icon: Click to pin/unpin the PTZ control
2: Pan/Tilt: Controls Pan/Tilt movement. Further you move away from the
middle, faster Pan/Tilt movement will be.
3: Zoom: Controls Zoom In/Out. Further you move away from the
middle, faster zooming will be.
4: Select Preset: Select a preset from the list of presets stored in the data
source.
5: GoTo: Go to the currently selected preset.
6: Set: Set the current PTZ position for the selected preset
7: Create: Create a new preset in the data source
8: Remove: Removes the currently selected preset from the data source
9: Refresh Presets: Updates the list of presets from the data source
