NetApp AFF A200 System Documentation page 672

Press release tab
Boot media
2. Press the blue button on the boot media housing to release the boot media from its housing, and then
gently pull it straight out of the boot media socket.
Do not twist or pull the boot media straight up, because this could damage the socket or the
boot media.
3. Move the boot media to the new controller module, align the edges of the boot media with the socket
housing, and then gently push it into the socket.
4. Check the boot media to make sure that it is seated squarely and completely in the socket.
If necessary, remove the boot media and reseat it into the socket.
5. Push the boot media down to engage the locking button on the boot media housing.
Step 3: Move the system DIMMs
To move the DIMMs, locate and move them from the old controller into the replacement
controller and follow the specific sequence of steps.
Steps
1. If you are not already grounded, properly ground yourself.
669
