TICs and Audio Riser Modules,
TIC LEDs
TIC module LEDs provide the following status information:
LED1. Illuminates to indicate communication loss with the host panel.
LED2. Illuminates when an RUI ground fault search is active.
LED3. Illuminates when Local Mode is active (4100-0625 Local Mode TIC only).
LED4. Illuminates to indicate an RUI Style 7 primary trouble.
LED5. Illuminates to indicate an RUI Style 7 secondary trouble.
TIC Specifications
Electrical Specifications
Input voltage
Output voltage
Input Current
Continued
Table 3. TIC (4100-0620, -0625) Specifications
18-33 VDC
8 V @ 1 A; 100 mV p-p ripple
87 mA maximum with no attachments (no 8V load)
(-0625) only)112 mA maximum with local mode annunciator (no
8V load)
With 100 mA load on 8V output – 130 mA @ 24 VDC, 140 mA
maximum over range
With 300 mA load on 8V output – 210 mA @ 24 VDC, 250 mA
maximum over range
With 1.0 A load on 8V output – 500 mA @ 24 VDC, 650 mA
maximum over range
5
