Non-Alarm Audio (NAA) Interface,
NAA Wiring
Refer to Figure16 to wire for the NAA Interface application
Continued
TO CUSTOMER-
SUPPLIED EQUIPMENT
Figure 16. Wiring for the Non-Alarm Audio (NAA) Interface Application
25
firealarmresources.com
4100-0623
NETWORK
AUDIO RISER
CONTROLLER
MODULE
4100-0622
DIGITAL
AUDIO
RISER
INTERFACE
OR THE
4100-1341 MCC
DIGITAL AUDIO RISER
INTERFACE
TB1
TB2
TB3
CHANNEL
NAA IN
DAR
OUT
