3. Press the <FUNCTION> key as required to display additional point status information.
NOTE: Any system point may be viewed on the alphanumeric display using the above procedure. Press
the required Prefix key, then use the Programmer's Report to identify the required point address.
Enter the required point address. Press the <FUNCTION> key to display information about the
point you entered.
An example of the Programmer's Report is shown in Figure 39.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
9245001B rev: 1
DOCUMENTATION
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
System Point Summary (ascending by zone name)
Zone
Name Custom Label
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
ZN1 BASEMENT NORTH WING ROOM 22
ZN2 BASEMENT NORTH WING ROOM 23
ZN3 BASEMENT NORTH WING ROOM 24
ZN4 BASEMENT NORTH WING ROOM 25
SIG1 BASEMENT NORTH WING HALLWAY 4
SIG2 BASEMENT NORTH HALLWAY 4 VISUAL
SIG3 FIRST FLOOR NORTH WING
SIG4 FIRST FLOOR NORTH WING VISUAL
AUX1 PRIMARY ELEVATOR CAPTURE
AUX2 ALTERNATE ELEVATOR CAPTURE
AUX3 1ST FLOOR NORTH WING SUPPLY FANS ON-AHU
FB1 PRIMARY ELEVATOR CAPTURE
FB2 ALTERNATE ELEVATOR CAPTURE
FB3 1ST FLOOR NORTH WING SUPPLY FANS AHUF
M1-1 3RD FLOOR EAST WING ROOM 12
M1-2 3RD FLOOR EAST WING ROOM 13
M1-3 3RD FLOOR EAST WING ROOM 14
M1-4 3RD FLOOR EAST WING ROOM 15
HOW TO DISPLAY THE SENSITIVITY OF A TrueAlarm
Use the following procedure to determine the sensitivity of a TrueAlarm
1. Using the 4100 Programmer's Report, locate the address of the desired sensor.
NOTE: The sensor address is in the format "C-DDD", where "C" is the MAPNET II
and 0), and "DDD" is the sensor number (1 through 127).
2. Lower the operator interface panel cover to gain access to all of the keypads.
3. Press the <MAP 6> key on the ENTRY keypad. The alphanumeric display now prompts you for the

MAPNET II channel and device number, as in the following example.
Please input Channel-Device (C-DDD)
MAPNET POINT: M
SYSTEM POINT SUMMARY
Figure 39

Typical Programmer's Report with Point Address Data

firealarmresources.com
15:37:52, MON, 04-APR-94
Point Type Device Type
PULL
SMOKE
DUCT
SFIRE
SSIG
RVIS
SSIG
RVIS
PRI
ALT
ON-OFF
ON-OFF
HEAT MBZAM
ALARM MBZAM
HEAT MBZAM
HMONITOR ADRDE

SENSOR

Sensor.
63
PAGE 3
POINT SUMMARY
ZONE
PNIS Code

channel (1 through 9,
