Page 1: Ant130L Series Single-Axis Linear Direct-Drive Nanopositioning Stage
ANT130L Series Single-Axis Linear Direct-Drive Nanopositioning Stage HARDWARE MANUAL Revision 2.00... - Page 2 Global Technical Support Portal for information and support about your Aerotech, Inc. products. The website supplies software, product manuals, Help files, training schedules, and PC-to-PC remote technical support. If necessary, you can complete Product Return (RMA) forms and get information about repairs and spare or replacement parts.
-
Page 3: Table Of Contents
ANT130L Hardware Manual Table of Contents Table of Contents ANT130L Series Single-Axis Linear Direct-Drive Nanopositioning Stage Table of Contents List of Figures List of Tables EU Declaration of Incorporation Safety Procedures and Warnings Installation and Operation Electrical Warnings Motor-Related Warnings... -
Page 4: List Of Figures
ANT130L Motor and Feedback Wiring [-CN1 Option] Figure 3-2: ANT130L Motor and Feedback Wiring [-CN2 Option] Figure 3-3: Machine Direction Figure 3-4: Hall Phasing Diagram Figure 3-5: Encoder Phasing Reference Diagram (Standard/Square Wave) Figure 3-6: Encoder Phasing Reference Diagram (Analog/Sine Wave) www.aerotech.com... -
Page 5: List Of Tables
List of Tables Table 1-1: Model Numbers and Ordering Options Table 1-2: Environmental Specifications Table 1-3: ANT130L Series Specifications Table 2-1: Stage Mounting Surface Flatness Requirement Table 2-2: Stage to Mounting Surface Hardware Table 2-3: Payload to Stage Surface Hardware... -
Page 6: Eu Declaration Of Incorporation
EU Declaration of Incorporation ANT130L Hardware Manual EU Declaration of Incorporation Manufacturer Aerotech, Inc. 101 Zeta Drive Pittsburgh, PA 15238-2811 herewith declares that the product: ANT130L Linear Stage is intended to be incorporated into machinery to constitute machinery covered by the Directive 2006/42/EC as amended;... -
Page 7: Safety Procedures And Warnings
To find the newest information about this product, refer to www.aerotech.com. If you do not understand the information in this manual, contact Aerotech Global Technical Support. IMPORTANT: This product has been designed for light industrial manufacturing or laboratory environments. -
Page 8: Installation And Operation
WARNING: Trip Hazard! Route, house, and secure all cables, duct work, air, or water lines. Failure to do so could introduce trip hazards around the system that could result in physical injury or could damage the equipment. www.aerotech.com... -
Page 9: Electrical Warnings
It is the responsibility of the End User/System Integrator to make sure that stages are properly connected and grounded per Engineering Standards and applicable safety requirements. It is the responsibility of the End User/System Integrator to configure the system drive or controller within the Aerotech motor/stage electrical and mechanical specifications. www.aerotech.com... -
Page 10: Motor-Related Warnings
Motor-Related Warnings ANT130L Hardware Manual Motor-Related Warnings Aerotech motors are capable of producing high forces and velocities. Obey all warnings and all applicable codes and standards when you use or operate a stage or system that incorporates Aerotech motors. DANGER: Hot Surface Hazard! The stage/motor frame temperature could exceed 70°C in some applications. -
Page 11: Pinch Points
(during normal operation, for example). when the system is moved manually (during the installation process or when you do maintenance, for example). Motors are capable of very high speeds and acceleration rates. Figure 1: Typical Pinch Point Locations www.aerotech.com... -
Page 12: Magnetic Hazards
Loose items such as metallic tools, watches, or keys could get drawn into and dam- age the magnet track assembly. IMPORTANT: Use non-magnetic tools when you install or do service to the stage. Figure 2: Exposed Magnet Locations www.aerotech.com... -
Page 13: Handling And Storage
Before you operate the stage, let it stabilize at room temperature for at least 12 hours. This will ensure that all of the alignments, preloads, and tolerances are the same as they were when they were tested at Aerotech. www.aerotech.com... - Page 14 Store the stage in the original shipping container. If the original packaging included ESD protective packaging, make sure to store the stage in it. The storage location must be dry, free of dust, free of vibrations, and flat. Section 1.1. Environmental Specifications Refer to www.aerotech.com...
-
Page 15: Chapter 1: Overview
Aerotech logo and the introduction of additive (3D-printed) parts. Refer to Figure 1-1. Contact Aerotech if you need a first generation manual. Figure 1-1: GEN2 vs GEN1 Visual Comparison Table 1-1: Model Numbers and Ordering Options... -
Page 16: Environmental Specifications
Indoor use only 1.2. Accuracy and Temperature Effects Aerotech products are designed for and built in a 20°C (68°F) environment. Extreme temperature changes could cause a decrease in performance or permanent damage to the stage. At a minimum, the environmental temperature must be controlled to within 0.25ºC per 24 hours to ensure the stage specifications are repeatable over an extended period of time. -
Page 17: Basic Specifications
6. -PL2 performance requires the use of an Aerotech controller. 7. To ensure the achievement and repeatability of specifications over an extended period of time, environmental temperature must be controlled to within 0.25°C per 24 hours. Consult the Aerotech factory for more information. www.aerotech.com... -
Page 18: Vacuum Operation
6. To reduce outgassing during the initial pump-down to vacuum pressure, Aerotech recommends that you bake out vacuum systems when you first install them into the vacuum chamber. Bake the vacuum components at 60 °C for 24 to 48 hours to desorb water vapor from surfaces and... -
Page 19: Chapter 2: Installation
IMPORTANT: The stage installation must be in accordance with the instructions provided by this manual and any accompanying documentation. Failure to follow these instructions could result in injury or damage to the equipment. 2.1. Dimensions Figure 2-1: ANT130L Dimensions www.aerotech.com... -
Page 20: Figure 2-2: Mounting Plate (Mp) Dimensions
2.1. Dimensions ANT130L Hardware Manual Figure 2-2: Mounting Plate (MP) Dimensions www.aerotech.com... -
Page 21: Securing The Stage To The Mounting Surface
Stage Mounting Surface Flatness Requirement Stage Travel Flatness Requirement All Travels 7.6 µm Access the mounting holes in the base of the stage by sliding the carriage all the way to either end of travel (shown in Figure 2-3). www.aerotech.com... -
Page 22: Figure 2-3: Mounting Hole Pattern
Refer to Section 2.1. for mounting locations and dimensions. Table 2-2: Stage to Mounting Surface Hardware Typical Screw Torque Mounting Hardware M6 x 18 mm (1/4 x 3/4 in) SHCS 7.0 N·m [61 lb·in] Figure 2-3: Mounting Hole Pattern www.aerotech.com... -
Page 23: Attaching The Payload To The Stage
If you start the ANT130L without a payload, the servo gains provided by Aerotech with the shipment may not be appropriate and servo instability can occur. Refer to the controller help file for tuning assistance. -
Page 24: Figure 2-4: Load Orientations
2.3. Attaching the Payload to the Stage ANT130L Hardware Manual Figure 2-4: Load Orientations www.aerotech.com... -
Page 25: Figure 2-5: Cantilevered Load Capabilities
ANT130L Hardware Manual 2.3. Attaching the Payload to the Stage Figure 2-5: Cantilevered Load Capabilities www.aerotech.com... - Page 26 2.3. Attaching the Payload to the Stage ANT130L Hardware Manual This page intentionally left blank. www.aerotech.com...
-
Page 27: Chapter 3: Electrical Installation
Aerotech motion control systems are adjusted at the factory for optimum performance. When the ANT130L is part of a complete Aerotech motion control system, setup should only require that you connect the stage to the appropriate drive chassis with the cables provided. Labels on the system components should indicate the appropriate connections. -
Page 28: Motor And Feedback Connectors
Stages equipped with standard motors and encoders come from the factory completely wired and assembled. IMPORTANT: Refer to the other documentation accompanying your Aerotech equipment. Call your Aerotech representative if there are any questions on system configuration. IMPORTANT: If using standard Aerotech motors and cables, motor and encoder connection adjustments are not required. -
Page 29: Table 3-1: 25-Pin Motor And Feedback Connector Pinout (-Cn1)
Hall Effect Sensor (Phase B) Frame Ground and Shield Connection Motor Phase A Motor Phase B Motor Phase C Table 3-2: 25-Pin Mating Connector Part Numbers Mating Connector Aerotech P/N Third Party P/N 25-Socket D-Connector ECK00300 FCI DB25S064TLF Backshell ECK00656 Amphenol 17E-1726-2... -
Page 30: Table 3-3: 4-Pin Motor Connector Pinout (-Cn2 Option)
Motor Phase C Reserved Reserved Reserved Reserved Reserved Frame Ground (motor protective ground) Table 3-4: 4-Pin Motor Mating Connector Part Numbers Mating Connector Aerotech P/N Third Party P/N Backshell ECK00656 Amphenol #17E-1726-2 Sockets [QTY. 4] ECK00659 ITT Cannon #DM53744-6 Connector ECK00657 ITT Cannon #DBM9W4SA197 www.aerotech.com... -
Page 31: Table 3-5: 25-Pin Feedback Connector Pinout (-Cn2 Option)
-/CCW LMT (End-of travel limit signal that indicates maximum permitted stage travel in the “machine negative” or “machine counter-clockwise” direction.) Reserved Table 3-6: 25-Pin Feedback Mating Connector Part Numbers Mating Connector Aerotech P/N Third Party P/N 25-Socket D-Connector ECK00300 FCI DB25S064TLF Backshell... -
Page 32: Motor And Feedback Wiring
3.2. Motor and Feedback Wiring ANT130L Hardware Manual 3.2. Motor and Feedback Wiring Shielded cables are required for the motor and feedback connections. Figure 3-1: ANT130L Motor and Feedback Wiring [-CN1 Option] www.aerotech.com... -
Page 33: Figure 3-2: Ant130L Motor And Feedback Wiring [-Cn2 Option]
ANT130L Hardware Manual 3.2. Motor and Feedback Wiring Figure 3-2: ANT130L Motor and Feedback Wiring [-CN2 Option] www.aerotech.com... -
Page 34: Motor And Feedback Specifications
Requires external pull-up to +5 V (10 kΩ recommended) Note: If the ANT130L is driven beyond the electrical limit, it will encounter a mechanical stop. Impacting the mechanical stop could cause damage to the stage even at low speeds. www.aerotech.com... -
Page 35: Table 3-11: Ant130L Motor Specifications
5. All performance and electrical specifications ±10%. 6. Maximum winding temperature is 125°C. 7. Ambient operating temperature range 0 °C - 25 °C; consult Aerotech for performance in elevated ambient temperatures. 8. All Aerotech amplifiers are rated Apk; use force constant in N·m/Apk when sizing. -
Page 36: Limits, Marker, And Machine Direction
ANT130L Hardware Manual 3.4. Limits, Marker, and Machine Direction Aerotech stages are configured to have positive and negative "machine" directions. The machine direction defines the phasing of the feedback and motor signals and is dictated by the stage wiring (refer to Section 3.2.). -
Page 37: Motor And Feedback Phasing
ANT130L Hardware Manual 3.5. Motor and Feedback Phasing 3.5. Motor and Feedback Phasing Motor phase voltage is measured relative to the virtual wye common point. Figure 3-4: Hall Phasing Diagram www.aerotech.com... -
Page 38: Figure 3-5: Encoder Phasing Reference Diagram (Standard/Square Wave)
3.5. Motor and Feedback Phasing ANT130L Hardware Manual Figure 3-5: Encoder Phasing Reference Diagram (Standard/Square Wave) Figure 3-6: Encoder Phasing Reference Diagram (Analog/Sine Wave) www.aerotech.com... -
Page 39: Chapter 4: Maintenance
Visually inspect the stage and cables. Re-tighten loose connectors. Replace or repair damaged cables. Clean the ANT130L and any components and cables as needed. Repair any damage before operating the ANT130L. Inspect and perform an operational check on all safeguards and protective devices. www.aerotech.com... -
Page 40: Cleaning And Lubrication
5. We recommend that you do not disassemble the stage beyond the instructions given in this manual. Proper assembly and calibration can only be done at the factory. Contact Aerotech for more information. Cleaning Use isopropyl alcohol on a lint-free cloth to clean any external metal surface of the ANT130L. - Page 41 4. Apply a thin, continuous film of lubricant to the exposed v-channels of the cross rollers on both ends of the stage. Aerotech recommends that you use a good quality, natural bristle artist's brush for the applicator. Do not use any applicator that could scratch or otherwise damage the v-channels.
-
Page 42: Troubleshooting
Chapter 3: Electrical Installation and Controller documentation). Stage moves uncontrollably Motor Connections (refer to Chapter 3: Electrical Installation and the Controller documentation). Gains misadjusted (refer to the Controller documentation). Stage oscillates or squeals Encoder signals (refer to the Controller documentation). www.aerotech.com... -
Page 43: Appendix A: Warranty And Field Service
All Other Repairs - After Aerotech's evaluation, the buyer shall be notified of the repair cost. At such time the buyer must issue a valid purchase order to cover the cost of the repair and freight, or authorize the product(s) to be shipped back as is, at the buyer's expense. - Page 44 Aerotech's approval. On-site Warranty Repair If an Aerotech product cannot be made functional by telephone assistance or by sending and having the customer install replacement parts, and cannot be returned to the Aerotech service center for...
-
Page 45: Appendix B: Revision History
Added Environmental Specifications section 1.02 Added safety information and warnings Added note about current requirements of motor and ground wires Added information on ANT130-L-Z 1.01 Added stage limit travel dimension -H option is now -PLUS option 1.00 New manual www.aerotech.com... - Page 46 Appendix B: Revision History ANT130L Hardware Manual This page intentionally left blank. www.aerotech.com...
-
