Typical Application Diagram - Altronix ACM4E Series Installation Manual

Fig. 1
Access Control
Panel
Output
NO
Relay
NC
SW1
ON
LED1
Mag.
ACM4CBE Lock
Electric
Strike
Keep power-limited wiring separate from non power-limited.
Use minimum 0.25" spacing.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture.
Replace fuses (ACM4E only) with the same type and rating, 3A/32V.
ACM4E/ACM4CBE Installation Guide

Typical Application Diagram:

C
Normally Open
N.O. Door
Releasing Device
IN GND IN GND IN GND
1 2 3
3A 3A
SW1 SW2
ON
ON
LED1 LED2
NC C NO COM NC C NO COM
OUTPUT1 OUTPUT2
Electromagnetic
Door Holders
Keypad
TRIGGER
INPUT
IN GND
4
SW4
3A 3A
ON
SW3
ON
LED3 LED4
NC C NO COM NC C NO COM
OUTPUT3 OUTPUT4
Mag. Lock
FACP
(Fire Alarm
Control Panel)
J3
TRG
FACP Interface Enabled
FACP Interface Disabled
J2 J1
10A
ACM4
ACCESS POWER
CONTROLLER
UL Listed
Power-Limited Power Supply
For this application
corresponding fuse
must be removed.
(ACM4 only)
Fig. 1a
FACP Dry
Form "C"
Output
SW1-SW4
Listed AC or DC Access
Control Power Supply
(optional)
Listed AC or DC Access
Control Power Supply
(required)
