Pre-installation and application warnings

This section highlights important information for this specific firmware and will assist in pricing accordingly, as
START HERE
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible
Vehicle Takeover
Firmware notes
Input/output configurations: Version 2.00 and higher use different input/output configurations and are not compatible with the
Š
wiring instructions of previous versions. Updating an older version to version 2.00 or higher will require wiring modifications.
Note: Damage to the vehicle may occur if the appropriate wiring modifications are not done.
T-Harness (THVWN1) notes:
Š
•All T-Harness wires not listed in the diagram are not required for the installation. Loose wires such as Siren Output and Hood
Input may need to be pulled from the tapped section of the T-Harness. Refer to the "Wiring diagram with T-Harness" for more
information on connections and installation instructions.
•The optional Plug & Play THVWN1 T-Harness is sold separately.
•OBDII Diagnostic Connector features: will remain the same even when the T-Harness is installed.
Fuses: It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed on each wiring
Š
diagram.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic connector.
Š
Refer to the "Vehicle connections" following the installation diagram.
Š
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory
hood pin, or if not supported in data.
[2] Siren: The siren is only required when enabling the security features during module flashing.
[3] Key Wrap: For Key Wrap instructions, refer to "Immobilizer interface with OEM immobilizer receiver".
[4] Starter, diodes, and brake: Starter connection is mandatory. Diodes and brake connections only required on vehicles
where brake needs to be depressed to start.
[5] Security-only: For Security-Only Installations, refer to 'Locating components in the vehicle' for the optional starter
disable connection.
