Directed Directechs DS3+ Installation Manual page 14

Module
Conn./Pin Color Description
H4/9 Red/White No Connection
H4/10 Pink No Connection
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin
H6/1
H6/2
H6/3
H6/4
Temperature sensor harness, 2-pin black connector (H7)
Module
Conn./Pin Color Description
H7/1 Black Temperature Sensor
H7/2 Black Temperature Sensor
14 933.VW10 2.00.195.3 2010 Volkswagen Jetta SportWagen
©2022 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
Color
N/A
N/A
Color
Blue
Black
Green
Red
Connects To
Wire Location
(+/-) Wire Color
Description
Description
(+/-) Wire Color
Connection
Connection
