Directed Directechs DS3+ Installation Manual page 13

Module
Conn./Pin Color Description
H2/15 White/Blue No Connection
H2/16 Red/Blue No Connection
H2/17 Black/White No Connection
H2/18 Orange/Black No Connection
H2/19 Blue No Connection
H2/20 Green No Connection
H2/21 Gray
(-) Hood Switch Input
H2/22 Violet/White No Connection
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. Parking Lights Interrupt (Conn. side)
H3/2 Blue/Red Relay N.O. (+) Parking Light Output
H3/3 Blue Relay COM. Parking Lights Interrupt (Veh. side)
H3/4 White/Brown Relay N.C. No Connection
H3/5 White Relay COM No connection
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red
Relay N.O. Key Wrap
H3/8 Lt. Green
Relay COM. Key Wrap
H3/9 Lt. Green/White
Relay N.C. Key Wrap
H3/10 Black (-) Ground
H3/11 White Relay COM. No Connection
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black No Connection
H4/3 Pink/Black No Connection
H4/4 Pink/White No Connection
H4/5 Red No Connection
H4/6 Green No Connection
H4/7 Violet No Connection
H4/8 Orange No Connection
13 933.VW10 2.00.195.3 2010 Volkswagen Jetta SportWagen
©2022 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
[1]
No Connection
Connects To
Wire Location
headlight switch, black 10 pin plug, pin 8
headlight switch, black 10 pin plug, pin 1
headlight switch, black 10 pin plug, pin 8
No Connection
No Connection
VESCM under driver dash, brown 52 pin plug, pin 42
[3] Not Applicable
[3] Not Applicable
[3] Not Applicable
No Connection
VESCM under driver dash, brown 52 pin plug, pin 42
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
(+/-) Wire Color Connection
cut red/white Mandatory
+ white/black Mandatory
cut red/white Mandatory
+ red/yellow (30A) Mandatory
Remote Start
Only
Remote Start
Only
Remote Start
Only
(chassis ground) Mandatory
+ red/yellow (30A) Mandatory
(+/-) Wire Color Connection
