Use
SETTINGS FILTRATION
Main filtration
The filtration cycles are set based on the duration. Start time is indicated by an "A" or "P" in the bottom right corner
of the display. Duration has no "A" or "P" indication. Each setting can be adjusted in 15-minute increments. The
panel calculates the end time and displays it automatically.
Main Screen
Press Menu/Select
repeatedly until
FLTR 1 appears.
To next
item in
Main Menu
Key
Indicates a change in the display.
Indicates a continuous or intermittent message - every 1/2 second.
+
- A temperature button, used for "Action"
Menu/Select button
Waiting time that keeps the last change to a menu item.
Wait time in which the initial settings are restored
by cancelling the changes made.
Filter cycle 2 - Optional filtering
Filter cycle 2 is OFF by default. It is possible to overlap Filter Cycle 1 and Filter Cycle 2, which will shorten overall
filtration by the overlap amount.
Purge Cycles
In order to maintain sanitary conditions, secondary Pumps will purge water from their respective plumbing by running
briefly at the beginning of each filter cycle.
If Filter cycle 1 is set for 24 hours, enabling Filter cycle 2 will initiate a purge when Filter cycle 2 is programmed to
begin.
Shows/flashes start time
to display RUN HRS
to display F1 ENDS xx:xx
Set
Set
Shows/flashes start time
to display RUN HRS
to display F2 ENDS xx:xx
Set
EN
Sets start hour Shows/flashes minutes
Sets Filter 1 length in hours Shows/flashes minutes
Set
*****
Wait a few seconds to
cancel the Filtration 1
Start Time and Hours and
return to the previous
Filtration 1 settings.
Main Screen
Wait a few seconds to
return to the
original setting
*****
Set
Sets start hour Shows/flashes minutes
Sets Filter 1 length in hours
Shows/flashes minutes
Set
*****
Wait a few seconds to
cancel the ON/OFF,
Filtration 2 Start Time and Hours
and return to the previous
Filtration 2 settings.
73
Quarz
minipool
Sets 15-minute increments
Wait a few seconds
to return to
the original setting
*****
Sets 15-minute increments
Wait to
Revert
*****
2X
Main Screen
Sets 15-minute increments Wait a few seconds
to return to the
original setting
*****
Sets 15-minute increments
Wait to
Revert
*****
2X
Main Screen
