Use
Navigation within the entire menu structure is possible us-
ing 2 or 3 keys on the control panel.
Some panels have separate WARM (+) and COOL (-) but-
tons, while others have a single temperature button.
In the navigation diagrams temperature buttons are
indicated by a single button icon.
Panels that have two temperature buttons (Warm and
Cool) can use both of them to simplify navigation and
programming.
The MENU/SELECT button is used to choose the various
menus and navigate each section.
When the numbers flash on the display it is possible to
set the temperature by simply pressing the tempera-
ture keys. The menus can be exited with certain button
presses. Simply waiting a few seconds, the control panel
will return to normal mode.
Power-up Screens
Each time the System powers up, a series of numbers
is displayed.
After the startup sequence of numbers, the system will
enter priming mode (see page 3).
Key
Indicates a change in the display.
Indicates a continuous or intermittent message - every 1/2 second.
+
- A temperature button, used for "Action".
Menu/Select button.
Waiting time that keeps the last change to a menu item.
Wait time in which the initial settings are restored by cancelling the
changes made.
EN
Main Screen
Menu/Select button
If the time is not
set "SET TIME"
will appear.
Indicates a Menu Item that Depends on a
Manufacturer Configuration and may or may
not appear.
Main Screen
Waiting a few seconds in the Main Menu will
allow the display to revert to the Main Screen.
+
-
Some changes are not saved unless
Refer to key above.
64
Quarz
minipool
Menu/Select is pressed.
