- Page 1 Muse GP Pre-installation manual READ AND FOLLOW ALL INSTRUCTIONS...
- Page 2 Proper preparation of the premises and systems will ensure a safe and rapid installation of the spa. For this reason we advise you to read this manual carefully and to carefully follow all the information contained herein.
-
Page 3: Table Of Contents
Contents 1 MEASUREMENTS AND TECHNICAL SPECIFICATIONS _________ 4 TEMPORARY POSITIONING ______________________________________________________________________ 5 WHAT PREPARATIONS ARE REQUIRED? _______________________ 6 PREPARATION OF CONNECTION TO AN OPTIONAL EXTERNAL EXCHANGER (NOT SUPPLIED) _________ 7 ARRANGEMENT FOR CONNECTION TO AN OPTIONAL OUTDOOR SPA PACK ________________________ 8 IDENTIFICATION OF THE INSTALLATION SITE __________________ 8 OUTDOOR INSTALLATION _______________________________________________________________________ 8 INDOOR INSTALLATION _________________________________________________________________________ 8... -
Page 4: Pre-Installation
Pre-Installation Muse GP MEASUREMENTS AND TECHNICAL SPECIFICATIONS 280 x 235 x 98 cm (110.24 x 92.52 x 38.58 inches) 2500 litres maximum water content (660 gal) Packaging Freestanding Recessed Drain Pipe 2950 kg insulation weight with The manufacturer suggests a... -
Page 5: Temporary Positioning
Pre-Installation Muse GP The spa works efficiently and safely if it is installed cor- rectly and in compliance with the regulations in force in the country of use. This pre-installation guide provides information for a proper preparation of the environments and the plumb- ing and electrical connections. -
Page 6: What Preparations Are Required
Pre-Installation Muse GP WHAT PREPARATIONS ARE REQUIRED? To be installed, the spa requires: Identification of the installation site. Room for the electrical Preparation of the installation site. connections Preparation of the drain. Preparation of the electrical system. a possible external heat exchanger (optional), see next page for details. -
Page 7: Preparation Of Connection To An Optional External Exchanger (Not Supplied)
Pre-Installation Muse GP PREPARATION OF CONNECTION TO AN OPTIONAL EXTERNAL EXCHANGER (NOT SUPPLIED) Room for the electrical connections The exchanger means the device that Inlet connection: heats water (in 1” 1/4 female this manual, it is Outlet connection: represented by a 1”... -
Page 8: Arrangement For Connection To An Optional Outdoor Spa Pack
Treesse spas are built to be positioned outdoors. If you install the spa inside, remember that it must be able to be easily inspected or moved for any ordinary and... -
Page 9: Freestanding Installations
Pre-Installation Muse GP PREPARATION OF THE INSTALLATION SITE Before preparing the supporting surface, see the sections on the electrical connections for posi- Prepare: tioning the connections correctly. A drainage grating around the perimeter to help • FREESTANDING INSTALLATIONS preserve the equipment and the structure (even for indoor installations). -
Page 10: Built-In Installations
Pre-Installation Pre-Installation Muse GP BUILT-IN INSTALLATIONS FOR THE RECESSED OUTDOOR INSTALLATIONS, to avoid damage due to freezing we recommend insulating As a base, create a reinforced concrete recess having a E the spa recess. This procedure prevents excessive thickness of at least 10 cm, perfectly flat and able to sup-... -
Page 11: Characteristics Of The Water Supply
Pre-Installation Muse GP CHARACTERISTICS OF THE WATER SUPPLY More information TAP WATER AND WELL WATER To ensure maximum hygiene and durability of the spa it is essential to pay close attention to the quality of the water that will be used to fill it. It is important that the water used be drinkable. It is always advisable not to use well water because it may be very hard, rich in metals like iron and manganese, and have bacterial loads. -
Page 12: Characteristics Of The Water Supply
...more likely uncontrollable changes in pH 80 and 125 mg/l (8-12.5°F) (CAT) ELECTRICAL PREPARATIONS The Treesse spas are built in compliance with UL laws (XXXXXXXX) and are tested during production to ensure the safety of the installer and user. The connection must be made by an experienced, qualified electrician. - Page 13 Pre-Installation Muse GP The Manufacturer is not responsible for connections made in a way that does not comply with local codes, the specifications in this manual or tampering with any electrical component of the spa. WARNING – This product is provided with a ground-fault circuit-interrupter (give location).
- Page 14 Pre-Installation Muse GP LEGEND C Electrical connection Exchanger pipe connection (if included) LEGEND C Electrical connection Exchanger pipe connection (if included) (measurements in cm)
- Page 15 Pre-Installation Muse GP THE IMAGE SHOWN HERE IS REPRESENTATIVE ONLY: MAKE THE ELECTRICAL CONNECTIONS FOLLOWING EXCLUSIVELY THE DIAGRAM (elec- trical diagram) SHOWN UNDER THE COVER OF YOUR CONTROL UNIT. J43 TO J13 (BLOWER ON J14) IN SETUPS 3, 5, 9, 11, 12, 17, 18 CLIM8ZONE ™...
- Page 16 Pre-Installation Muse GP THE IMAGE SHOWN HERE IS REPRESENTATIVE ONLY: MAKE THE ELECTRICAL CONNECTIONS FOLLOWING EXCLUSIVELY THE DIAGRAM (elec- trical diagram) SHOWN UNDER THE COVER OF YOUR CONTROL UNIT. MOVE WIRE TO CONNECT J2O TO J13 J5 (A1-A4) FOR BLOWER IN SETUPS 3 & 4 CONNECT ONLY TO CIRCUITS PROTECTED BY A CLASS A GFCI.
- Page 17 Notes Notes...
- Page 18 Notes Notes...
- Page 19 Maximum care has been paid to guarantee the accuracy of this manual. The Manufacturer reserves the right to modify the equipment or the documentation at any time, without notice. Therefore, there might be small differences between this manual and the product you have received: we apologise in advance for any inconvenience. The total or partial reproduction of this manual without the Manufacturer's consent is prohibited.
- Page 20 www.gruppotreesse.it GRUPPO TRE S s.p.a. 01036 Nepi (VT) - Italy S.S. Cassia km. 36.400 Settevene industrial area tel. (+39) 0761 527242 fax (+39) 0761 527223 info@gruppotres.it...
