CHAPTER
5
VISUALIZE SPRAY DATA
To visualize data for field operations what is injected the last hour in case of the main flow.
1. From the RCM-Sprayer main page, select the Diagnostics softkey.
FIGURE 1. Product 2 Operation Page
2. Select the Tests tab, select the product 2 (P2) button.
Diagnostics and Troubleshooting: Visualize Spray Data
D IAGNOSTICS AND
C H A P T E R 5
TROUBLESHOOTING
19
