- Page 1 Vending, s.a. Vending SERIE Elite E l i t e SERVICE AND SPARE MANUAL C:\manuales\Elite\inglés\ELITEing10-02.DOC Pág 1 de 49 Edición:09/02...
-
Page 2: Working Characteristics
Vending, s.a. WORKING CHARACTERISTICS. • The alarm LED lights up every 5 seconds. • The out of change LED indicates that the number of coins available for change is under a predetermined level. • The out of product LED will only light up if the whole machine is empty. -
Page 3: Machine Installation
Vending, s.a. MACHINE INSTALLATION • Unpack the machine. Remove outside and inside packing (Elite 24 models). • Level the machine properly. Using the levelling knobs at the bottom of the machine, adjust height until the machine is perfectly level. • Plug into mains. Connect to a 220 Volt / 50 Hertz source. - Page 4 Vending, s.a. TESTS • Testing communication between cards. The red LED on all cards should blink, while the green LED should be continuously lit. If you press a selection the price should appear on the display. Inserting a pack in any one slide will remove the out of product indication. In all cards, the green LED indicates that there is a power supply and that it is receiving commands, while the red LED indicates communication.
-
Page 5: Control Electronics
Vending, s.a. CONTROL ELECTRONICS Control electronics for the machines consists of several cards connected to one another through a serial bus with MDB protocol. Three of these cards have their own microprocessor and their own program that can write on the micro (Motor Card) or in a separate memory (Control and Display Cards). Diagrama funcional de las tarjetas. - Page 6 Vending, s.a. card. It has its own microprocessor and program which are included in the same chip. There are three variants for drawing 57000 where the factory standard extractor connections can be seen, depending on machine model. Working example: • The machine is waiting for a sale ... The Control Card is sending the Display Card information on the current time so that the Display Card can show it.
- Page 7 Vending, s.a. RETAINING HOOK Elite There are two parts with the same shape in the machines: The difference between the two machines is in the retaining hook length. The short retaining hook part adapts to longer cigarette packs, such as Winston, Marlboro, Fortuna, Ducados, Camel etc. The part with the long retaining hook(white) should be used for the slides that carry Lucky Strike or similar packs.
- Page 8 Vending, s.a. PHOTOGRAPHY Photography take apart. Photography assembly. Is the same but in inverse process. C:\manuales\Elite\inglés\ELITEing10-02.DOC Pág 8 de 49 Edición:09/02...
- Page 9 Vending, s.a. Programming Manual Elite SERIE C:\manuales\Elite\inglés\ELITEing10-02.DOC Pág 9 de 49 Edición:09/02...
- Page 10 Vending, s.a. PROGRAMMING PUSH The programming push are the elements that allow us check and insert the information when a programming operation is done. Example: change the price of products. Reject Push Button Programm Push Button Selection Push P1-P2-P3-P4 • Programming Push Button. This push is in the display board, inside the door. This push has two functions: 1 Enter and exit of programming mode.
- Page 11 Vending, s.a. • Reloading return tubes. (OPTION IS ONLY ACTIVATED WHEN THERE IS A CHANGE GIVER IN THE MACHINE AND IT IS OPERATING) By entering this option all types of coins which do not go to the return tubes are inhibited.
- Page 12 Vending, s.a. (OPTION IS ONLY ACTIVATED WHEN THERE IS A CHANGE GIVER IN THE MACHINE AND IT IS OPERATING) To program prices of products in each channel, enter programming option 00.03. When you press a channel the product price appears on the display. If you do not wish to change it, just press any other channel so that the price of the pressed channel appears, or alternatively press the PROGRAMMING button.
- Page 13 Vending, s.a. • Manual handling of motors. To handle the motors in each channel manually, enter programming option 00.04. By pressing a channel the associated motors will move in sequence. Each time a motor is moved the display will show the push-button number which is being moved and the number of the motor (e.g.
- Page 14 Vending, s.a. These are sales made since the machine was purchased. They cannot be reset to zero. Each time a channel is pressed the number of products sold corresponding to that channel appears on the display. If the number is higher than 9999 (the four digits on the display), the figure will appear on the display, advancing from right to left.
- Page 15 Vending, s.a. Once in this option (and with the printer connected) press channel 1. The display shows ‘r232’ flashing and starts to send characters to the printer. When this is finished it shows the value 09.05 again. You can print as many tickets as you like.
- Page 16 Vending, s.a. display. This product code is a number between 0 and 9999. If you do not want to change it just press REJECT or the PROGRAMMING button. This second action will take you to the next option of those available in the programming mode.
- Page 17 Vending, s.a. 00.13: Only sale at exact price 01.13: Change is not returned 02.13: Maintain change temporarily on the display 03.13: Maintain change permanently on the display To exit this option and pass to the next one while storing the value, press PROGRAMMING.
- Page 18 Vending, s.a. • Programming of minimum coin levels. Once inside option 00.15 (programming the minimum number of coins which the coin return, below which the machine indicates that it has no change) just press the channels (3 or 4 channels depending on the change giver coin mechanism) located top right in the machine.
- Page 19 Vending, s.a. option 01.18. Within this option, when you press channel 1 the time (hours and minutes) when the application of the discount/surcharge on sales will appear (the minutes flash). To change the value, use the first push-button = 500 located in the top right-hand corner of the machine (Channel 1).
- Page 20 Vending, s.a. right-hand corner of the machine. Each one represents a digit on the display. With each keystroke in each channel the digit corresponding to that channel in a unit increases, and when it reaches 9 it goes to 0, etc. Once you have seen the code you want to enter, press the REJECT button to validate it.
- Page 21 Vending, s.a. • programming coin value Desactivate • Activate programming coin value. (THIS OPTION IS ONLY ACTIVATED WHEN THERE IS A VALIDATOR IN THE MACHINE AND IT IS OPERATING) Allows us to change the value of the coins accepted by the coin selector, modify the number of decimals, choose the language for display messages and determine the inhibition level of the validator.
- Page 22 Vending, s.a. • Tone dialing mode for telephone number (02.28). • Pulse dialing mode for telephone number (12.28) This option is used to tell the modem how to dial. Press coin return to switch between dialling modes. To exit this option press the programming button. •...
- Page 23 Vending, s.a. the machine will perform a cycle of the extractors, moving each one 50 times. If you want to interrupt this cycle press REJECT until the machine finishes the E l i t e turn is it making and detects this push-button. The display will show the value 51.
- Page 24 Vending, s.a. Advice Codes. Switch off and on the machine. If the display flashes, press the programming push-button while the display flashes and test if the problem has disappeared. If it doesn’t work yet, the following list shows you the messages the machine can show in the display to help you to solve the problem.
