GMC Pontiac Solstice 2009 Service Manual

Document ID: 1246749
|
2009 Pontiac Solstice
Cigar Lighter Receptacle or 12-Volt Accessory Power
Receptacle Replacement
Tools Required
J 42059 Cigar Lighter Socket Remover
Removal Procedure
1. Remove the auxiliary power outlet fuse from the fuse block.
2. Remove the receptacle:
2.1. Look into the receptacle. There are two 3 mm (0.11 in) tab windows 12 mm (0.47 in)
from the front of the receptacle. The
windows and the receptacle can be pulled straight out.
2.2. Place one side of the "T" portion of the
not fit straight into the receptacle. Angle the
receptacle.
2.3. Insert the other side of the "T" into the opposite tab window.
You must move the
2.4. Use the J 42059
http://localhost:9001/si/showDoc.do?docSyskey=1246749&pubCellSyskey=122652&pub...
SKY, Solstice (VIN M) Service Manual
| Document ID: 1246749
Repair Instructions
J 42059 handle toward horizontal to engage the other tab window.
to pull the receptacle straight out.
© 2010 General Motors Corporation. All rights reserved.
|
Power and Signal Distribution
J 42059 pushes the plastic latches from these tab
J 42059 into the tab window. The
J 42059 slightly for insertion into the
Page 1 of 3
| |
Power Outlets
J 42059 will
