SET COMMUNICATION:

This section define the fundamental communication parameters of two buses, IEC61850
and BACnet.
By Pressing the "Set Communication" button from the main window for SW67767
(Fig. 2) the window "Set Communication" appears (Fig. 3).
The means of the fields for "IEC61850 Client" are:
In the fields "IP Address" the IP address for IEC61850 side of the converter is
defined;
In the fields "SubNet
converter is defined;
In the fields "Gateway" the default gateway of the net is defined. This feature
can be enabled or disabled pressing the Check Box field. This feature is used for
going out of the net;
In the field "VLAN" the identifier for the VLAN is defined;
In the field "Application
In the section "BACnet Master" it is possible to select the type of BACnet to use from:
BACnet/IP (it uses Ethernet);
BACnet MS/TP (it uses RS485).
If selected "BACnet/IP" the means of the fields for "BACnet" are:
In the fields "IP ADDRESS" the IP address of BACnet/IP side of the converter is
defined;
In the fields "SUBNET
converter is defined;
In the fields "GATEWAY" the default gateway of the network is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature is
used for going out of the net;
ADFweb.com Srl – IT31010 – Mareno – Treviso
Mask" the SubNet Mask for IEC61850 side of the
ID" the Goose identification string is defined.
Mask" the SubNet Mask of BACnet/IP side of the
User Manual IEC61850 Client / BACnet Slave
Document code: MN67767_ENG Revision 1.000
Figure 3: "Set Communication" window
