In the field "Port" the port used for BACnet communication is defined. The default port used for BACnet communication is 47808, but
is possible to insert any value;
In the field "BACnet Device
In the field "Device Identifier" the device instance of BACnet/IP side of the converter is defined;
If the field "BACnet description up to 32
If selected "BACnet MS/TP" the means of the fields for "BACnet" are:
In the field "Baudrate" the baudrate of BACnet MS/TP side of the converter is defined;
In the field "Parity" the parity of BACnet MS/TP side of the converter is defined;
In the field "BACnet Device
In the field "MAC Address" the MAC of BACnet MS/TP side of the converter is defined;
The field "Max Masters" specifies the highest allowable address for master nodes. The value shall be less than or equal to 127;
The field "Max Info Frames" specifies the maximum number of information frames the node may send before it must pass the
token;
In the field "Device Istance" it is possible to assign a number to the BACnet node (used for the Device Istance);
In the field "Network" the BACnet MS/TP network number is defined;
If the field "BACnet description up to 32
ADFweb.com Srl – IT31010 – Mareno – Treviso
Name" the name of BACnet/IP side of the converter is defined;
chars" is checked, the description of the BACnet objects can be up to 32 chars.
Name" the name of BACnet MS/TP side of the converter is defined;
chars" is checked, the description of the BACnet objects can be up to 32 chars.
