Industrial Electronic Devices
User Manual
Revision 1.000
English
DMX / BACnet Master - Converter
(Order Code: HD67704-IP-B2)
For Website information:
www.adfweb.com?Product=HD67704
For Price information:
www.adfweb.com?Price=HD67704-IP-B2
Benefits and Main Features:
Very easy to configure
Triple electrical isolation
Temperature range: -40°C/85°C (-40°F/185°F)
User Manual
ADFweb.com S.r.l.
User Manual DMX / BACnet Master
Document code: MN67704_ENG
For others BACnet Master products see also the following link:
Converter BACnet Master to
www.adfweb.com?Product=HD67712
www.adfweb.com?Product=HD67714
www.adfweb.com?Product=HD67716
www.adfweb.com?Product=HD67717
www.adfweb.com?Product=HD67718
www.adfweb.com?Product=HD67719
www.adfweb.com?Product=HD67721
www.adfweb.com?Product=HD67722
www.adfweb.com?Product=HD67723
www.adfweb.com?Product=HD67725
www.adfweb.com?Product=HD67726
www.adfweb.com?Product=HD67801
www.adfweb.com?Product=HD67832
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
Revision 1.000
Page 1 of 28
(Modbus Slave)
(Modbus TCP Slave)
(PROFIBUS Slave)
(CAN)
(CANopen)
(PROFINET)
(DeviceNet Slave)
(EtherNet/IP)
(NMEA 2000)
(J1939)
(SNMP Agent)
(KNX)
(DALI)
Advertisement
Table of Contents
Related Manuals for ADF Web HD67704-IP-B2
Summary of Contents for ADF Web HD67704-IP-B2
- Page 1 Page 1 of 28 Industrial Electronic Devices User Manual Revision 1.000 English DMX / BACnet Master - Converter (Order Code: HD67704-IP-B2) For Website information: www.adfweb.com?Product=HD67704 For Price information: www.adfweb.com?Price=HD67704-IP-B2 Benefits and Main Features: For others BACnet Master products see also the following link:...
-
Page 2: Table Of Contents
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 2 of 28 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you INDEX that you need to check that the following document is: UPDATED DOCUMENTATION Updated REVISION LIST... -
Page 3: Security Alert
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 3 of 28 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 4 of 28 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 5 of 28 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67704-IP-B2 ADFweb.com S.r.l. -
Page 6: Characteristics
Page 6 of 28 Industrial Electronic Devices CHARACTERISTICS: The HD67704-IP-B2 is a converter from BACnet Master to DMX and vice-versa. They allows the following characteristics: Up to 512 BACnet objects in reading and 512 objects in writing; Triple isolation between Serial - Power Supply, Serial - Ethernet, Ethernet - Power Supply;... -
Page 7: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67704-IP-B2 Caution: Not reverse the polarity power HD67704-IP-B2 ADFweb.com S.r.l. -
Page 8: Function Modes
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 8 of 28 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip1 of Dip-Switch A’... -
Page 9: Leds
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 9 of 28 Industrial Electronic Devices LEDS: The device has got five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode ON: Device powered... -
Page 10: Rs485
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 10 of 28 Industrial Electronic Devices RS485: For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure. The maximum length of the cable should be 1200m (4000 feet). Here some codes of cables: Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;... -
Page 11: Ethernet
The Ethernet port is used for BACnet/IP communication and for programming the device. The Ethernet connection must be made using Connector2 of HD67704-IP-B2 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC is recommended the use of a cross cable. -
Page 12: Use Of Compositor Sw67704
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 12 of 28 Industrial Electronic Devices USE OF COMPOSITOR SW67704: To configure the Converter, use the available software that runs with Windows called SW67704. It is downloadable from the site www.adfweb.com and its operation is described in this document (this manual is referenced to the last version of the software present on our web site). -
Page 13: New Configuration / Open Configuration
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 13 of 28 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “DMX / BACnet Master - Converter”... -
Page 14: Software Options
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 14 of 28 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 15 User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 15 of 28 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 16: Set Communication
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 16 of 28 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, BACnet and DMX. By Pressing the “Set Communication” button from the main window for SW67704 (Fig. 2) the window “Set Communication”... - Page 17 User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 17 of 28 Industrial Electronic Devices If selected “BACnet MS/TP” the means of the fields for “BACnet” are: In the field “Baudrate” it is possible to select the baudrate of the BACnet (9600, 19200, 38400, 57600, 76800, 115200);...
-
Page 18: Set Bacnet Access
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 18 of 28 Industrial Electronic Devices SET BACNET ACCESS: By Pressing the “Set BACnet Access ” button from the main window of SW67704 (Fig. 2), the window “Set BACnet Access” appears (Fig. Figure 4a: “Set BACnet Access BACnet Read”... - Page 19 User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 19 of 28 Industrial Electronic Devices In the field “D Adr” the address of the endpoint is defined. If “D Len” is ‘1’ it is possible to insert a number from 1 to 255; if “D Len” is ‘2’...
- Page 20 User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 20 of 28 Industrial Electronic Devices Figure 4b: “Set BACnet Access BACnet Write” window The means of the fields in the window (Write) are the following: In the field “IP Address / ID”...
- Page 21 User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 21 of 28 Industrial Electronic Devices In the field “Poll Time” the frequency of the request is defined (in ms); In the field “Max Error” the number of consecutive errors that the Master waits before stopping the specific requests is defined; In the field “Channel”...
-
Page 22: Dmx Default Value
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 22 of 28 Industrial Electronic Devices DMX DEFAULT VALUE: By pressing the “DMX Default Value” button from the main window for SW67704 (Fig. 2) the “DMX Default Value” window appears (Fig. 5). In this section it is possible to define the default value for each channel of the DMX array when the converter is turned ON. -
Page 23: Update Device
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 23 of 28 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. If you don’t know the actual IP address of the device you have to use this procedure: Turn off the Device;... - Page 24 User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 24 of 28 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67704 device.
-
Page 25: Mechanical Dimensions
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 25 of 28 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67704-IP-A1 ADFweb.com S.r.l. -
Page 26: Ordering Informations
IP: BACnet/IP MSTP: BACnet MS/TP Device Family HD67704: DMX / BACnet Master - Converter Order Code: HD67704-IP-B2 DMX / BACnet/IP Master – Converter ACCESSORIES: Order Code: AC34001 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC Order Code: AC34002 35mm Rail DIN - Power Supply 110V AC 50/60Hz –... -
Page 27: Disclaimer
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 27 of 28 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 28: Warranties And Technical Support
User Manual DMX / BACnet Master Document code: MN67704_ENG Revision 1.000 Page 28 of 28 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
