4
Plug the power cord head into the DC-1/DC-2 connector on A48.
.
Warning: The above figure shows the DC power supply terminal block. It is the lugs
at the wiring end from the power source. The wiring procedure is for
ground-to-ground, positive-to-positive, and negative-to-negative in order. The
ground wire should always be connected first and disconnected last.
23
User's Guide
