Levelflex M FMP41C with FOUNDATION Fieldbus
Parameter Position
Indicator
measured value 000
tank properties 002
medium property 003
process propert. 004
end of probe 030
probe length 031
probe 032
probe length 033
determine length 034
empty calibr. 005
full calibr. 006
echo quality 056
check distance 051
range of mapping 052
start mapping 053
pres. map dist. 054
delete mapping 055
offset 057
output damping 058
upper block.dist 059
output on alarm 010
outp. echo loss 012
ramp %span/min 013
delay time 014
safety distance 015
in safety dist. 016
Endress + Hauser
11.5.5 Methods
The FOUNDATION Fieldbus specification provides for the use of so-called methods to simplify the
operation of the device. A method is an interactive sequence of steps that must be followed in order
to obtain a particular function from the device.
The Levelflex M has got the following methods:
• Basic setup
• Safety settings
• Acknowledge alarm
• Length adjustment
• Linearisation
• Extended calibration
• Output
• System parameters
• Lock TB Manufacturer parameters
Most of these methods are identical to the respective function group in the operating menu. A
detailed description of them can be found in the "Description of Instrument functions", BA245F/
00/en.
11.5.6 Parameter list of the Levelflex M Sensor Block
rel. Variable Name
Index
18 PARMEASUREDVALUE
19 PARTANKPROPERTIES
20 PARMEDIUMCONDITION
21 PARPROCESSPROPERTIES
22 PARENDOFPROBE
23 PARPROBESHORTEND
24 PARPROBEFREE
25 PARPROBELENGTH
26 PARPROBELENGTHSETUP
27 PAREMPTYCALIBRATION
28 PARFULLCALIBRATION
29 PARECHOQUALITY
30 PARCHECKDISTANCE
31 PARSUPPRESSIONDISTANCE
32 PARSTARTMAPPINGRECORD
33 PARPRESMAPRANGE
34 PARDELETEMAPPING
35 PAROFFSETOFMEASUREDDISTANCE
36 PAROUTPUTDAMPING
37 PARHIGHBLOCKINGDISTANCE
38 PAROUTPUTONALARM
39 PARREACTIONLOSTECHO
40 PARRAMPINPERCENTPERMIN
41 PARDELAYTIMEONLOSTECHO
42 PARLEVELWITHINSAFETYDISTANCE
43 PARINSAFETYDISTANCE
Size Type Access Storage
[bytes]
4 FloatingPoint RO
1 Unsigned8 RW
1 Unsigned8 RW
1 Unsigned8 RW
1 Unsigned8 RW
1 Unsigned8 RW
1 Unsigned8 RW
4 FloatingPoint RW
1 Unsigned8 RW
4 FloatingPoint RW
4 FloatingPoint RW
2 Integer16 RO
1 Unsigned8 RW
4 FloatingPoint RW
1 Unsigned8 RW
4 FloatingPoint RO
1 Unsigned8 RW
4 FloatingPoint RW
4 FloatingPoint RW
4 FloatingPoint RW
1 Unsigned8 RW
1 Unsigned8 RW
4 FloatingPoint RW
2 Unsigned16 RW
4 FloatingPoint RW
1 Unsigned8 RW
Appendix
Changeable
Class in Mode
dynamic Auto, OOS
static OOS
static OOS
static OOS
static OOS
dynamic OOS
dynamic OOS
static OOS
dynamic OOS
static OOS
static OOS
dynamic Auto, OOS
dynamic OOS
dynamic OOS
dynamic OOS
dynamic Auto, OOS
dynamic OOS
static OOS
static Auto, OOS
static OOS
static OOS
static OOS
static OOS
static OOS
static OOS
static OOS
