Levelflex M FMP41C with FOUNDATION Fieldbus
Endress + Hauser
Source of supply
Host System
ABB (Field Controller 800)
Allen Bradley (Control Logix)
Endress+Hauser (ControlCare)
Honeywell (Experion PKS)
Invensys
SMAR (System 302)
Emerson (Delta V)
Yokogawa (CENTUM CS 3000)
5.4.3 Representation of parameters
A FOUNDATION Fieldbus configuration tool offers two types of parameter representation:
•Representation by parameter name
Examples: "PAROPERATIONCODE", "PARRESET"
•Representation by parameter label
(identical to the labels on the display module VU331 and in an Endress+Hauser operation tool)
Examples: "unlock parameter", "reset"
5.5 Operation with the handheld terminal
Field Communicator 375/FC375
5.5.1 Connection
The handheld terminal is directly connected to the FOUNDATION Fieldbus communication line.
An additonal communication resistor is not required.
5.5.2 Instrument Descriptions
Make sure you have loaded the valid Instrument Description files (DDs). DDs can be downloaded
from the internet at "www.fieldcommunicator.com". The DDs can also be updated by the update
functionality of the Field Communicator 375/FC375.
5.5.3 User interface
The instrument parameters are arranged in blocks. The handheld terminal Field Communicator
375/FC375 uses this block structure to access the parameters. You can navigate within the
structure by the arrow keys and the "Enter" key. Alternatively, you can use the touch-screen
functionality of the handheld terminal for navigation. (Double-click on a name opens the respective
block or parameter).
Source of supply for the Instrument Description and Network Configuration
files
• www.endress.de (-> Download -> Media type = "Software", "Instrument Drivers")
• CD-ROM (Endress+Hauser order code: 56003896)
• www.fieldbus.org
• www.easydeltav.com
• www.yokogawa.com
Operation
37
