Levelflex M FMP41C with FOUNDATION Fieldbus
Tolerance of probe length
Weight
Material
Endress + Hauser
10.1.7 Mechanical construction
over
up to
admissible tolerance (mm / inch)
over
up to
admissible tolerance (mm / inch)
Levelflex M FMP41C
+ rod probe
Weight for the F12 approx. 3.5 kg
or T12 housing +
approx. 1.1 kg/
metre
Probe length
+
Flange weight
Weight for the F23 approx. 6.8 kg
housing +
approx. 1.1 kg/
metre
Probe length
+
Flange weight
• Housing:
– housing F12/T12: aluminium (AlSi10Mg), seawater-resistant, powder-coated
– housing F23: 316L, corrosion-resistant steel
• Sight window: glass
Rod probes
1 m / 3.2 ft
1 m / 3.2 ft 3 m / 9.8 ft
- 5 / - 0.2 - 10 / - 0.4
Rope probes
1 m / 3.2 ft
1 m / 3.2 ft 3 m / 9.8 ft
- 10 / - 0.4 - 20 / - 0.8
FMP41C
+ rope probe
approx. 3.5 kg
+
approx. 0.5 kg/m
Probe length
+
Flange weight
approx. 6.8 kg
+
approx. 0.5 kg/m
Probe length
+
Flange weight
Technical data
3 m / 9.8 ft 6 m / 20 ft
6 m / 20 ft
- 20 / - 0.8 - 30 / - 1.2
3 m / 9.8 ft 6 m / 20 ft
6 m / 20 ft
- 30 / - 1.2 - 40 / - 1.6
