Commissioning
ENDRESS + HAUSER
⇒
–
+ E
ENDRESS + HAUSER
⇒
–
+ E
50
Function "determine lenght" (034)
Use this function, the probe length can be determined automatically.Due tu the mounting
conditions, the automatically determined probe length may be larger than the actual probe (typically
20 ... 30 mm longer). This has no influence on the measuring accuracy. When entering the empty
value for a linearisation, please use the "empty calibration" istead of the automatically determined
probe length.
Selection:
• length ok
• to short
• to long
After selection "length too short" or "lenght too long", the calculation of the new value need approx. 10s.
Function "empty calibr." (005)
This function is used to enter the distance from the flange (reference point of the measurement) to
the minimum level (=zero)
E
Levelflex M FMP41C with FOUNDATION Fieldbus
E = empty calibration (= zero)
0%
L00-FMP4xxxx-14-00-06-en-008
