Levelflex M FMP41C with FOUNDATION Fieldbus
Endress + Hauser
20 Probe:
B ..... mm, rope PFA>316, 300mm, Center rod, nozzle height max 300mm
C ..... mm, rope PFA>316, 450mm, Center rod, nozzle height max 450mm
D ..... inch, rope PFA>316, 6inch, Center rod, nozzle height max 6inch
E ..... inch, rope PFA>316, 12inch, Center rod, nozzle height max 12inch
G ..... inch, rope PFA>316, 18inch, Center rod, nozzle height max 18inch
K ..... mm, rod PFA>316L
M ..... inch, rod PFA>316L
Y Special version, to be specified
30 Process connection:
AEK 1-1/2" 150lbs RF, PTFE >316/316L flange ANSI B16.5
AFK 2" 150lbs RF, PTFE >316/316L flange ANSI B16.5
AGK 3" 150lbs RF, PTFE >316/316L flange ANSI B16.5
AHK 4" 150lbs RF, PTFE >316/316L flange ANSI B16.5
AJK 6" 150lbs RF, PTFE >316/316L flange ANSI B16.5
AQK 1-1/2" 300lbs RF, PTFE >316/316L flange ANSI B16.5
ARK 2" 300lbs RF, PTFE >316/316L flange ANSI B16.5
ASK 3" 300lbs RF, PTFE >316/316L flange ANSI B16.5
ATK 4" 300lbs RF, PTFE >316/316L flange ANSI B16.5
CEK DN40 PN16-40, PTFE >316L flange EN1092-1 (DIN2527 C)
CFK DN50 PN10-40, PTFE >316L flange EN1092-1 (DIN2527 C)
CGK DN80 PN10/16, PTFE >316L flange EN1092-1 (DIN2527 C)
CHK DN100 PN10/16, PTFE >316L flange EN1092-1 (DIN2527 C)
CJK DN150 PN10/16, PTFE >316L flange EN1092-1 (DIN2527 C)
CSK DN80 PN25/40, PTFE >316L flange EN1092-1 (DIN2527 C)
CTK DN100 PN25/40, PTFE >316L flange EN1092-1 (DIN2527 C)
KEK 10K 40, PTFE >316L flange JIS B2220
KFK 10K 50, PTFE >316L flange JIS B2220
KGK 10K 80, PTFE >316L flange JIS B2220
KHK 10K 100, PTFE >316L flange JIS B2220
MRK DIN11851 DN50 PN40, PTFE >316L
TCK Tri-Clamp ISO2852 1-1/2", PTFE >316L
TDK Tri-Clamp ISO2852 2", PTFE >316L
TFK Tri-Clamp ISO2852 3", PTFE >316L
TJK Tri-Clamp ISO2852 1-1/2", PTFE >316L, 3A EHEDG
TLK Tri-Clamp ISO2852 2", PTFE >316L, 3A EHEDG
TNK Tri-Clamp ISO2852 3", PTFE >316L, 3A EHEDG
UPK Universal adapter 44mm, PTFE >316L
UQK Universal adapter 44mm, PTFE >316L, EHEDG 3A
YY9 Special version, to be specified
40 Power Supply; Output:
B 2-wire; 4-20mA SIL HART
D 2-wire; PROFIBUS PA
F 2-wire; FOUNDATION Fieldbus
G 4-wire 90-250VAC; 4-20mA SIL HART
H 4-wire 10.5-32VDC; 4-20mA SIL HART
K 2-wire; 4-20mA HART, interface measurement
Y Special version, to be specified
50 Operation:
1
2
3
9
60
70
W/o display, via communication
4-line display VU331, envelope curve display on site
Prepared for FHX40, remote display (accessory)
Special version, to be specified
Type of probe:
1 Compact, basic version
3 Remote, cable 3m, top entry
4 Remote, cable 3m, side entry
9 Special version, to be specified
Housing:
A F12 Alu, coated IP68 NEMA6P
B F23 316L IP68 NEMA6P
C T12 Alu, coated IP68 NEMA6P, separate conn. compartment
D T12 Alu, coated IP68 NEMA6P + OVP
Y Special version, to be specified
Identification
1)
, separate conn. compartment
9
