Jumpers
Jumpers
This section describes functionality of the configuration jumpers.
Figure 2-3
shows the jumper locations.
Figure 2-3. Jumper Locations
Power Jumpers (P14-15)
Remove jumpers listed in
across the adjacent sense resistor.
Table 2-1. Power Jumpers
Power Jumper
P14
P15
2-4
Table 2-1
Resistor
VDD_INT
VDD_EXT
ADSP-BF706 EZ-KIT Mini Evaluation System Manual
to measure the respective voltage
