Connectors

Audio Input/Output ( P29 and P28)

The analog audio ADC input P29 and DAC output P28 connectors are configured as a stereo single ended signal

for connection to the first two inputs and outputs of the AD1937.

Part Description

3.5mm Stereo Jack

Standard 3.5mm stereo audio male cable

This connector interfaces with SigmaStudio+ through the

the schematic.

This connector has multiple signals interfaced with AD2437 IC. This connector can be interfaced with external cus-

tom boards if required or used for probing. The connector is a 0.1" header. The pinout can be found in the sche-

matic.

B Interface ( P32)

This connector has A

B processor signals. It can be interfaced with external custom boards if required. The pinout

can be found in the schematic.

Note that when using this connector on the SOMCRR board, please ensure that the evaluation board is set as a

main node and JP1 is not connected if 2 step discovery is required.

This section describes functionality of the configuration jumpers. The Jumper Locations figure shows the jumper

locations. Please refer A

3–4

Manufacturer

CUI

Mating Cable

B Software quick start guide for final Jumper settings.

Part Number

SJ1-3525NG

EVAL-ADUSB2EBZ

board. The pinout can be found in
