Part Description

3.5mm Stereo TRS Connector

Multipurpose pins ( P5 )

Bi-directional pins designed for multipurpose use. For further information please refer to the schematic.

P10 is an I2C header compatible with the USBi adapter for direct programming of the ADAU1701 through Sig-

maStudio+.

P15 provides access to the AD243x SPI port for interfacing with external peripherals. The connector has 0.1" head-

ers. The pinouts can be found in the schematic.

This section describes functionality of the configuration jumpers. The Jumper Locations figure shows the jumper

locations.

EVAL-AD2437B1NZ Manual

Manufacturer

CUI Devices

Part Number

SJ-3523-SMT

Connectors

3–5
