Ref. Qty. Description
11 1 0.33UF 16V 10% 0603
X7R
12 1 IDC 4X1 IDC4X1
13 1 12.288MHZ
OSCL254P500X320
14 6 1UF 16V 10% 0603 X5R C46-C51
15 2 1UF 16V 10% 0805 X7R C25,C55
16 1 GREEN LED_0603
17 1 USB-MICRO 5PIN
HIROSE_ZX62D-AB-5P8
18 1 RED LED_0603
19 1 YELLOW LED_0603
20 1 15KV ESDA5V3SC6
SOT95P280X145-6N
21 1 MIC2025-1 SOIC8
22 1 25MHZ OSC013
23 1 24MHZ OSC013
24 1 74LCX125MX
SOIC127P600-14N
25 2 3.5MM STEREO
CON_SJ1-3515-SMT
26 1 150UF 10V 10% D
TANT-LOW-ESR
27 1 47.5K 1/10W 1% 0603
28 3 330.0 1/16W 1% 0402
29 9 100K 1/16W 5% 0402
30 1 76.8K 1/16W 1% 0402
A-2
Reference
Designator
C52
P9
U6
LED2
P8
LED1
LED0
D1
U7
Y1
Y2
U5
J1,J2
CT1
R45
R47,R51,R52
R17,R19-R21,R41,
R42,R53,R60,R70
R71
ADSP-BF706 EZ-KIT Mini Evaluation System Manual
Manufacturer Part Number
AVX 0603YC334KAT2A
BERG-FCI 54101-T08-04LF
DIGI-KEY 535-10982-2-ND
DIGI-KEY 399-5090-2-ND
DIGI-KEY 399-1284-2-ND
DIGI-KEY 475-1409-2-ND
DIGI-KEY H11494CT-ND
DIGI-KEY 475-2512-2-ND
DIGI-KEY 475-2558-1-ND
DIGI-KEY 497-6633-1-ND
DIGI-KEY 576-1057-ND
DIGI-KEY 535-9140-1-ND
DIGI-KEY 535-9138-2-ND
DIGI-KEY 74LCX125MXTR-ND
DIGI-KEY CP1-3515SJGRTR-ND
DIGI-KEY 478-3321-2-ND
DIGI-KEY 311-47.5KHRTR-ND
DIGI-KEY 541-330LCT-ND
DIGI-KEY 541-100KJTR-ND
DIGI-KEY 541-76.8KLCT-ND
