Table 3-3: SoM Interface C Connector (P16) (Continued)
Pin Signal
9 ETH0_GPIO_1
10 ETH1_RXD0
11 ETH0_GPIO_2
12 ETH1_TXEN
13 ETH0_RXD3
14 ETH1_TXD0
15 ETH0_RXD2
16 ETH1_TXD1
17 ETH0_RXD1
18 ETH1_CRS
19 ETH0_RXD0
20 ETH1_INTb
Table 3-4: Mating Connector
Part Description
100-pin, 0.64 mm
100-pin, 0.64 mm

Power Plug ( P14)

This powers up the board with a 24V supply. Power is required when the board is operating in both main and sub
mode.
Part Description
2.1 mm power jack
24.0VDC @3A power supply

Jumpers

This section describes functionality of the configuration jumpers. The Jumper Locations figure shows the jumper
locations.
EVAL-AD2437A1NZ Manual
Pin Signal
29 ETH0_TXD2
30 ETH0_PTPPPS1
31 ETH0_TXD1
32 ETH0_PTPPPS2
33 ETH0_TXD0
34 ETH0_PTPPPS3
35 ETH0_TXCLK
36 GND5
37 ETH0_TXEN
38 SYS_CLKOUT
39 GND6
40 AUDIO_CLK
Manufacturer
SAMTEC
Mating Connector
SAMTEC
Manufacturer
CUI
Mating Cable
Kaga Electronics USA
Pin Signal
49 PPI_FS3
50 JTG0_TCK/
SWCLK
51 PPI_D00
52 JTG0_TDO/SW0 72
53 PPI_D01
54 JTG0_TDI
55 PPI_D02
56 JTG0_TRST
57 PPI_D03
58 TARGET_RESET 78
59 PPI_D04
60 GND9
Part Number
LSS-150-01-L-DV-A-K
LSS-150-01-L-DV-A-K
Part Number
PJ-102AH
KTPS65-2430DT-3P-VI-C-P1
Pin Signal Pin Signal
69 PPI_D09 89 VDD_VREF
70 PPI_D21 90 GND12
71 PPI_D10 91 VDD_A
PPI_D22 92 VDD_DMC
73 PPI_D11 93 VDD_INT
74 PPI_D23 94 SYS_HWRST
75 PPI_D12 95 PWR_SEQ_GOOD
76 GND10 96 SoM_Reset
77 PPI_D13 97 VDD1
ETH1_R 98 VSS1
EFCLK
79 PPI_D14 99 VDD2
80 UART3_ 100 VSS2
TX
Connectors
3–9
