2.2 RQI-55(-E), RQI-53(-E)

Processor Intel® Core™ i5-8400H 45W
Cores
Base Freq.
MAX Turbo
Freq.
Chipset Mobile Intel® CM246
16GB DDR4 2400MHz installed,
Memory
single SODIMM (max 32GB)
Display 2x DP++ and 1x HDMI
Ethernet 4x Intel® GbE: 3x i211AT + 1x i219 iAMT support
Serial Ports COM1/2: RS-232/422/485
2x USB 3.1 Gen1 Type A with lockable connectors
USB 4x USB 3.1 Gen 1 Type A
4x USB 2.0 Type A
• Two channels I
• 8x Digital Input: VIH: 2 to 5.25V; VIL: 0 to 0.8V
Multi-I/Os on
• 8x Digital Output: VOH: 2.4 to 5V; VOL: 0 to 0.5V; current:
DB 50
24mA/per channel
connector
Optional (if modules installed on system):
(supports
• Dual Channel: FARO-FP900, PEAK IPEH-003049*
real time OS)
• Single Channel: PEAK IPEH-003048*
*Note: Modules support real time OS
Mini PCIe 2x full size (one for CANbus, one for Wi-Fi or LTE)
M.2 1x Socket 1, Key A and A+E key, 2230 for Wi-Fi
USIM 1 for Mini PCIe
TPM 2.0 Supported
• Watchdog Timer
LED • Drive Activity
Indicators • Diagnostic
• 5x User Defined
6
RQI-55(-E)
System Core
4
2.5 GHz
4.2 GHz
I/O Interface
2
C
RQI-53(-E)
Intel® Core™ i3-9100HL 25W
4
1.6 GHz
2.9 GHz
8GB DDR4 2400MHz installed,
single SODIMM (max 32GB)
Specifications
