Technical
Information
TI322P/00/en
Pressure Transmitter
cerabar M PMP 46
cerabar M PMP 48
Overload resistant pressure transmitter with
diaphragm seal and analogue, Smart or
PROFIBUS-PA electronics
PMP 48
Flange
Applications
The Cerabar M transmitter measures the
gauge and absolute pressure of gases,
vapours and liquids and can be used in
all areas of industry.
Installation and process conditions often
make the use of diaphragm seals
necessary. Endress+Hauser offers you
the following:
• PMP 46: diaphragm seals for hygienic
applications
• PMP 48: diaphragm seals with
threaded boss, separator, flange or
flange with extension
Endress
The Power of Know How
PMP 46
Clamp
Features and Benefits
• Accuracy
− Linearity better than 0.2% of set span
− Adjustable measuring range with
TD 10:1
− Long-term stability better than 0.1%
• Piezoresistive metal sensor with metal
diaphragm for measuring ranges up to
400 bar (6000 psi).
• Electronics
− Analogue: cost effective version with
short response time especially for
fast processes
− Smart: intelligent with versatile
operating procedures via HART
protocol
− PROFIBUS-PA: tried and tested for
digital communications
• Housing
With its stainless steel housing and no
dead volume, the Cerabar M fulfils all
the special hygienic requirements of
the food and pharmaceutical
industries. The polyester-epoxy
coated aluminium housing has proven
itself well in the process industry.
• Process connections
All customary thread versions,
hygienic connections and flanges
available.
+
Hauser

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the cerabar M PMP 46 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Endress+Hauser cerabar M PMP 46

Summary of Contents for Endress+Hauser cerabar M PMP 46

  • Page 1 Technical Pressure Transmitter Information TI322P/00/en cerabar M PMP 46 cerabar M PMP 48 Overload resistant pressure transmitter with diaphragm seal and analogue, Smart or PROFIBUS-PA electronics PMP 46 Clamp PMP 48 Flange Features and Benefits • Accuracy − Linearity better than 0.2% of set span −...
  • Page 2 Construction Diaphragm Connection Page/Version Standard Nominal width Pressure Instrument type seal range Hygienic Diaphragm Groove nut Page 21 DIN 11851 DN 32, max. 40 bar PMP 46 applications seal DN 40, (600 psi) DN 50 Page 23 1½", 2" Page 23 1½", 2"...
  • Page 3 PMP 48 DXR 275 handheld terminal at any e.g. flange point along the 4…20 mA line, or − via PC e.g. with the Endress+Hauser Commuwin II operating program. • PROFIBUS-PA: Operation: – Using a PC with an operating program, e.g.
  • Page 4 Instrument Configuration of Cerabar M with Aluminium Housing Displays A display module can be used for low cover raised cover showing measured values and for with sight glass for display simplifying local operation. The display is plugged onto the electronic insert using a holder.

  • Page 5: Measuring System

    − supply voltage, e.g. with the transmitter power supply unit from RN 221N transmitter power supply Endress+Hauser unit from Endress+Hauser Supply voltage: 11.5…45 V DC Supply voltage: 11.5…45 V DC or Ex ia: 11.5…30 V DC • Cerabar M pressure transmitter with −...

  • Page 6: Operating Principle

    Piezoresistive Sensor with Operating Principle Diaphragm Seal The process pressure acting on the diaphragm of the diaphragm seal is transmitted to the metallic separating diaphragm of the sensor by the filling fluid of the diaphragm seal. The separating diaphragm is deflected and the fluid transmits the pressure to a resistance bridge.

  • Page 7: Operation

    It can then be operated either by means of a handheld terminal or an operating program (e.g. Endress+Hauser Commuwin II). Analogue Electronics Operating elements For the Cerabar M with analogue electronics lower range-value (Zero)
  • Page 8 PROFIBUS-PA Electronics • The digital display gives the pressure A Cerabar M with PROFIBUS-PA electronics has the following operating as a four-digit number. The bar graph options. depicts the current pressure value • You can set a damping of between 0 related to the measuring range.
  • Page 9 HART protocol to the RS 232 C serial interface of a personal computer. This enables the transmitter to be remotely operated with the Endress+Hauser Commuwin II operating program. You can connect the Commubox FXA 191 at any point along the 4…20 mA line.

  • Page 10: Installation

    (see page 12). Mounting with Temperature Spacer Endress+Hauser recommends the use of a temperature spacer when extreme media temperatures (from approx. 150°C/302°F) continually cause the ambient temperature to exceed the permissible limit of +85°C (+185°F).
  • Page 11 Mounting with Capillary Tubing Installation To protect from high temperatures (max. (Continuation) 350°C/+662°F media temperature), moisture, vibration, or where the mounting point is not easily accessible, the housing of the Cerabar M can be mounted with a capillary tubing away from the measuring point.
  • Page 12 Diaphragm Seal Filling Fluid Guidelines for Mounting Capillary Design Planning for Tubes The temperature and pressure of the the Diaphragm Seal process are of critical importance when The transmitter should generally be selecting the filling fluid for the mounted below the tapping point. A diaphragm seal.

  • Page 13: Electrical Connection

    Wiring Analogue and Smart Electrical Connection Electronics • Internal protection circuits against The two-wire cable is connected to screw terminals on the electronic insert. reverse polarity, HF interference and • Supply voltage: 11.5…45 V DC; overvoltage peaks. • Test signal: additional for Smart electronics Ex ia: 11.5…30 V DC The output current can be measured...
  • Page 14 Connection Harting Plug (PROFIBUS-PA) For hygienic applications or humid For applications in power stations, there Endress+Hauser also provides a operating areas, Endress+Hauser also is a Cerabar M with a Han7D Harting Cerabar M with a M12 plug. This version offers a Cerabar M with a M12 plug with...

  • Page 15: Technical Data

    Technical Data General Information Manufacturer Endress+Hauser Instrument Pressure transmitter Designation Cerabar M PMP 46, PMP 48 Technical documentation TI322P/00/en Version 03.05 Technical data according to DIN 19259 Application Measurement of absolute and gauge pressure in gases, vapours, liquids and dusts...
  • Page 16 Input (Continuation) Resistance to low pressures (vacuum resistance) to 10 mbar (0.15 psia) absolute Adjusting the span (turn down) to TD 10:1 (see also this page figure 2) Zero point increase and Analogue – ±10% within extended measurement limits decrease Smart –...
  • Page 17 Process conditions Installation conditions Any position Zero point shift due to position can be corrected, see page 16, " Zero point increase and decrease" Ambient conditions Ambient temperature –40…+85°C (–40…+185°F) For instruments approved for use in hazardous areas, see Safety Instructions (XA…), Installation Drawing (CSA) or Control Drawing (FM).
  • Page 18 Corresponds to table 4, IEC 61158-2 Certificates and Approvals Ignition protection see "Product Structure, Certificates" CE Mark By attaching the CE Mark, Endress+Hauser confirms that the instrument fulfils all the requirements of the relevant EC directives. Order Code see "Product Structure"...

  • Page 19: Product Structure

    Product Structure Cerabar M PMP 46 PMP 46 Certificates R Standard G ATEX II 1/2 G, EEx ia IIC T6 H ATEX II 2 G, EEx ia IIC T6 N ATEX II 3 G, EEx nA II T5 K ATEX II 1/2 D, EEx ia IIC T6...
  • Page 20 Diaphragm and Pipe Seal for Hygienic Applications Material 1.4435 (AISI 316L) Diaphragm seal AG Dairy thread DIN 11851, DN 32, PN 40 Dairy thread DIN 11851, DN 40, PN 40 Dairy thread DIN 11851, DN 50, PN 40 DG Clamp, 1½", PN 40 Clamp, 2", PN 40 DU Clamp, 3", PN 40 SMS thread,1½", PN 40...
  • Page 21 Diaphragm Seal Pipe Diaphragm Seal Dimensions Conical Sleeve with Groove Nut DIN 11851 (Dairy Thread) PMP 46 DIN 11851 (Dairy Thread) Conversion factors • 1 mm = 0.039 in 1 in = 25.4 mm • 1 kg = 2.2 lbs 1 lbs = 0.45 kg •...
  • Page 22 Clamp Diaphragm Seal Clamp Pipe Diaphragm Seal Dimensions PMP 46 Conversion factors • 1 mm = 0.039 in 1 in = 25.4 mm • 1 kg = 2.2 lbs 1 lbs = 0.45 kg • 1 bar = 14.5 psi 1 psi = 0.069 bar Process connection •...
  • Page 23 SMS Sleeve with Groove Nut RJT Sleeve with Groove Nut Dimensions PMP 46 Conversion factors • 1 mm = 0.039 in 1 in = 25.4 mm • 1 kg = 2.2 lbs 1 lbs = 0.45 kg • 1 bar = 14.5 psi 1 psi = 0.069 bar ISS Sleeve with Groove Nut Process connection...
  • Page 24 0.1 235.5 252.5 PMP 46 10.5 from 0.1 239.5 258.5 Welding Flange Endress+Hauser offers a welding flange ø105 with PTFE flat packing for the ø66 flush-mounted installation of the DRD ø50 flange (version KL). Material: 1.4435 (AISI 316L) ø125 Order No.: 52002041...
  • Page 25 Product Structure Cerabar M PMP 48 PMP 48 Certificates R Standard G ATEX II 1/2 G, EEx ia IIC T6 H ATEX II 2 G, EEx ia IIC T6 N ATEX II 3 G, EEx nA II T5 K ATEX II 1/2 D, EEx ia IIC T6 ATEX II 1/3 D (non-Ex power supply) C CSA General Purpose CSA IS (suitable for Div.
  • Page 26 Product Structure Process Connection Material 1.4435 (AISI 316L) Process Connections Threaded boss PMP 48 G 1, DIN ISO 228/1 AG G 1½, DIN ISO 228/1 G 2, DIN ISO 228/1 1 NPT, ANSI B 1.201 BG 1½ NPT, ANSI B 1.201 2 NPT, ANSI B 1.201 Separator with G ½, EN 837, Form 6kt Separator with ½...
  • Page 27 G Threaded Boss NPT Threaded Boss Dimensions PMP 48 Conversion factors • 1 mm = 0.039 in 1 in = 25.4 mm • 1 kg = 2.2 lbs 1 lbs = 0.45 kg • 1 bar = 14.5 psi 1 psi = 0.069 bar Process connection •...
  • Page 28 Separator with G ½ A; EN 837 Separator with ½ NPT, Dimensions Form B 6kt ANSI B 1.20.2 PMP 48 Conversion factors • 1 mm = 0.039 in 1 in = 25.4 mm • 1 kg = 2.2 lbs 1 lbs = 0.45 kg •...
  • Page 29 DIN Flange DIN Flange with Extension Dimensions PMP 48 Conversion factors • 1 mm = 0.039 in 1 in = 25.4 mm • 1 kg = 2.2 lbs 1 lbs = 0.45 kg • 1 bar = 14.5 psi 1 psi = 0.069 bar Flange •...
  • Page 30 ANSI Flange ANSI Flange with Extension Dimensions PMP 48 Conversion factors • 1 mm = 0.039 in 1 in = 25.4 mm • 1 kg = 2.2 lbs 1 lbs = 0.45 kg • 1 bar = 14.5 psi 1 psi = 0.069 bar Flange •...
  • Page 32 Endress+Hauser GmbH+Co. KG Instruments International P.O. Box 2222 D-79574 Weil am Rhein Germany Tel. (0 76 21) 9 75-02 Fax (0 76 21) 9 75-3 45 http://www.endress.com info@ii.endress.com Endress Hauser The Power of Know How 05.02/PT1 TI322P/00/en/03.05 CCS/CV5...
