TI00437P/00/EN/23.22-00
71581317
2022-07-27
Products
Technical Information
Deltapilot M FMB50, FMB51,
FMB52, FMB53
Hydrostatic level measurement
Pressure transmitter with CONTITE™ measuring
cell (condensate-resistant)
Application
The device is used for the following measuring tasks:
• Hydrostatic pressure measurement in liquids and paste-like media in all areas of
process engineering, process measuring technology, pharmaceuticals and the food
industry
• Level, volume or mass measurement in liquids
Your benefits
• Very good reproducibility and long-term stability
• Maximum plant safety provided by one-of-a-kind, condensate-resistant CONTITE
measuring cell
• High reference accuracy: ±0.2 %
optionally ±0.1 %
• Turn down up to 100:1
• Uniform platform for differential pressure, hydrostatics and pressure (Deltabar M
– Deltapilot M – Cerabar M)
• Simple, fast commissioning through a user interface designed for real-world
applications
• Used for process pressure monitoring up to SIL 2, certified to IEC 61508 Edition
2.0 and IEC 61511 by TÜV NORD
• Usage in drinking water: KTW, NSF
Solutions
Services
