Directed DIRECTECHS DS4+ Installation Manual page 11

Wire Information
Function Color
Subaru Tribeca 2006
HS CAN High Red
HS CAN Low Blue
Immobilizer Data 1 White/Blue
Immobilizer Data 2 Black/Pink
FT CAN High Pink
FT CAN Low Violet
Keyless Data Yellow/Green
Security Light Brown/Red
Keysense Red or Black/White
Brake Brown/Red
12V White
Accessory Yellow
Ignition Green
Ignition 2 Blue
Starter White/Black
Parking lights Orange
11
Pin Polarity Location
20 Data Body Integrated Unit, B280, right of steering column.
30 Data Body Integrated Unit, B280, right of steering column.
18 Data Body Integrated Unit, B280, right of steering column.
28 Data Body Integrated Unit, B280, right of steering column.
27 Data Body Integrated Unit, i84, right of steering column.
26 Data Body Integrated Unit, i84, right of steering column.
9 Data Body Integrated Unit, i84, right of steering column.
33 (-) Body Integrated Unit, i84, right of steering column.
7 (+) Body Integrated Unit, B281, right of steering column.
23 (+) Body Integrated Unit, B281, right of steering column.
3 (+) Ignition Switch, B72, at steering column.
4 (+) Ignition Switch, B72, at steering column.
6 (+) Ignition Switch, B72, at steering column.
1 (+) Ignition Switch, B72, at steering column.
2 (+) Ignition Switch, B72, at steering column.
4 (+) Parking Light Switch, B69, at steering column.
Connector Information
Color
White
White
White
White
Gray
Gray
Gray
Gray
White
White
White
White
White
White
White
White
© 2017-03-07 Directed. All rights reserved.
Pins Ref.
30 A
30 A
30 A
30 A
35 B
35 B
35 B
35 B
28 C
28 C
6 D
6 D
6 D
6 D
6 D
4 E
DS4+ SUBARU1
