Directed DIRECTECHS DS4+ Installation Manual page 14

Wire Information
Function Color
Subaru Legacy 2007-2009
HS CAN High Red
HS CAN Low Blue
Immobilizer Data 1 White/Blue
Immobilizer Data 2 Black/Pink
FT CAN High Pink
FT CAN Low Violet
Keyless Data Yellow/Green
Security Light Brown/Red
Keysense Red or Black/White
12V White
Accessory Yellow
Ignition Green
Ignition 2 Blue
Starter White/Black
Parking lights Orange
Subaru Outback 2007-2009
HS CAN High Red
HS CAN Low Blue
Immobilizer Data 1 White/Blue
Immobilizer Data 2 Black/Pink
FT CAN High Pink
FT CAN Low Violet
Keyless Data Yellow/Green
Security Light Brown/Red
Keysense Red or Black/White
12V White
Accessory Yellow
Ignition Green
Ignition 2 Blue
Starter White/Black
Parking lights Orange
Subaru Tribeca 2007-2014
HS CAN High Red
HS CAN Low Blue
Immobilizer Data 1 White/Blue
Immobilizer Data 2 Black/Pink
FT CAN High Pink
FT CAN Low Violet
Keyless Data Yellow/Green
Security Light Brown/Red
Keysense Red or Black/White
12V White
Accessory Yellow
Ignition Green
Ignition 2 Blue
Starter White/Black
Parking lights Orange
14
Pin Polarity Location
20 Data Body Integrated Unit, B280, right of steering column.
30 Data Body Integrated Unit, B280, right of steering column.
18 Data Body Integrated Unit, B280, right of steering column.
28 Data Body Integrated Unit, B280, right of steering column.
27 Data Body Integrated Unit, i84, right of steering column.
26 Data Body Integrated Unit, i84, right of steering column.
9 Data Body Integrated Unit, i84, right of steering column.
33 (-) Body Integrated Unit, i84, right of steering column.
7 (+) Body Integrated Unit, B281, right of steering column.
3 (+) Ignition Switch, B72, at steering column.
4 (+) Ignition Switch, B72, at steering column.
6 (+) Ignition Switch, B72, at steering column.
1 (+) Ignition Switch, B72, at steering column.
2 (+) Ignition Switch, B72, at steering column.
4 (+) Parking Light Switch, B69, at steering column.
20 Data Body Integrated Unit, B280, right of steering column.
30 Data Body Integrated Unit, B280, right of steering column.
18 Data Body Integrated Unit, B280, right of steering column.
28 Data Body Integrated Unit, B280, right of steering column.
27 Data Body Integrated Unit, i84, right of steering column.
26 Data Body Integrated Unit, i84, right of steering column.
9 Data Body Integrated Unit, i84, right of steering column.
33 (-) Body Integrated Unit, i84, right of steering column.
7 (+) Body Integrated Unit, B281, right of steering column.
3 (+) Ignition Switch, B72, at steering column.
4 (+) Ignition Switch, B72, at steering column.
6 (+) Ignition Switch, B72, at steering column.
1 (+) Ignition Switch, B72, at steering column.
2 (+) Ignition Switch, B72, at steering column.
4 (+) Parking Light Switch, B69, at steering column.
20 Data Body Integrated Unit, B280, right of steering column.
30 Data Body Integrated Unit, B280, right of steering column.
18 Data Body Integrated Unit, B280, right of steering column.
28 Data Body Integrated Unit, B280, right of steering column.
27 Data Body Integrated Unit, i84, right of steering column.
26 Data Body Integrated Unit, i84, right of steering column.
9 Data Body Integrated Unit, i84, right of steering column.
33 (-) Body Integrated Unit, i84, right of steering column.
7 (+) Body Integrated Unit, B281, right of steering column.
3 (+) Ignition Switch, B72, at steering column.
4 (+) Ignition Switch, B72, at steering column.
6 (+) Ignition Switch, B72, at steering column.
1 (+) Ignition Switch, B72, at steering column.
2 (+) Ignition Switch, B72, at steering column.
4 (+) Parking Light Switch, B69, at steering column.
Connector Information
Color
White
White
White
White
Gray
Gray
Gray
Gray
White
White
White
White
White
White
White
White
White
White
White
Gray
Gray
Gray
Gray
White
White
White
White
White
White
White
White
White
White
White
Gray
Gray
Gray
Gray
White
White
White
White
White
White
White
© 2017-03-07 Directed. All rights reserved.
Pins Ref.
30 A
30 A
30 A
30 A
35 B
35 B
35 B
35 B
28 C
6 D
6 D
6 D
6 D
6 D
4 E
30 A
30 A
30 A
30 A
35 B
35 B
35 B
35 B
28 C
6 D
6 D
6 D
6 D
6 D
4 E
30 A
30 A
30 A
30 A
35 B
35 B
35 B
35 B
28 C
6 D
6 D
6 D
6 D
6 D
4 E
DS4+ SUBARU1
