- Page 1 CIP Training Pro C5300 series Throughput...
-
Page 3: Startup And Shutdown
CIP Training Pro C5300 series Throughput Startup and Shutdown. Front and left view 1. Auto Document Feeder (ADF) Lower the ADF over originals placed on the exposure glass. If you load a stack of originals in the ADF, the ADF will automatically feed the originals one by one. -
Page 4: Turning On/Off The Power
CIP Training Pro C5300 series Throughput Turning On/Off the Power • Do not push the main power switch repeatedly. • When you push the main power switch, wait at least 10 seconds after it is confirmed that the main power indicator has lit up or gone out. -
Page 5: Turning Off The Main Power
CIP Training Pro C5300 series Throughput Turning Off the Main Power • When disconnecting the power cord from the wall outlet, always pull the plug, not the cord. Pulling the cord can damage the power cord. Use of damaged power cords could result in fire or electric shock. - Page 6 CIP Training Pro C5300 series Throughput Fusing Unit Off Mode In this mode, the main power indicator is lit. Because the heater of the fusing unit is turned off but the screen of the control panel is still displayed, the power consumption decreases, but you can start operation promptly.
- Page 7 CIP Training Pro C5300 series Throughput Adding/Replacing Toner bottles You can view the procedure to replace the toner by watching a movie that is displayed on the control panel. • Replace the toner after the message prompting replacement is displayed on the control panel.
-
Page 8: Supply Yields
Coverage 8.75%, A4 Note: The toner yield targets are based on the average coverage given at standard conditions on uncoated A4 paper recommended for the Ricoh C5300s Series. Actual yields may vary depending on individual conditions. Recycle: Ricoh consumable recycling Our consumable recycling program is free to our customers as part of our goal to reach zero waste-to-land ll. - Page 9 CIP Training Pro C5300 series Throughput When Paper or an Original Is Jammed Remove the jammed sheet by following the procedure described in the animated illustration displayed on the control panel. If paper jams occur frequently, check that the actual paper size in the tray, the paper size dial and the [Tray/Paper Settings] displayed on the control panel are the same.
- Page 10 CIP Training Pro C5300 series Throughput • When you close the upper right cover of the machine while the bypass tray is closed, be sure to push the mark on the bypass tray, not the upper right cover. • When you close the upper right cover of the machine while the bypass tray is open, push the mark on the upper right cover.
- Page 11 CIP Training Pro C5300 series Throughput 1. Check the part where the paper jam occurred on the screen. When the display is turned off, press [Check] in [Check Status] "Mach. Status". 2. Follow the procedure described in the animated illustration to remove the jammed paper.
